GE HEALTHCARERAFT VOLUSON E8 / VOLUSON E6
D
IRECTION KTD102576, REVISION 7 DRAFT (AUGUST 23, 2012) SERVICE MANUAL
8-4 Section 8-2 - System Software - Installation/Upgrade Procedure
8-2-4 Preparations (cont’d)
1.) Press the UTILITIES
key on the control panel.
2.) In the “Utilities” menu touch SYSTEM SETUP
to invoke the setup desktop on the screen.
3.) On the left side of the screen select ADMINISTRATION
and then click the SYSTEM INFO tab, to see
which Software/Hardware version is installed in the unit.
Figure 8-1 Version check (System Setup - Administration - SYSTEM INFO page)
currently installed Ultrasound
Application Software version
Date of Factory Settings
Voluson E8
(e.g., BT09)
To Next Page
