GE Voluson E6

GE HEALTHCAREDRAFT VOLUSON E8 / VOLUSON E6
D
IRECTION KTD102576, REVISION 7 DRAFT (AUGUST 23, 2012) SERVICE MANUAL
Chapter 9 - Renewal Parts 9-7
* Difference between RTU4 and RTU5: RTU 5 has [ELASTO] button.
NOTE: The installed Console version is shown in the System Info page (see: Figure 7-1 on page 7-3).
Table 9-4 User Interface
Item Part Name Part Number Description Qty CRU FRU
201
Cable Holder
KTZ134656 Probe Cable Holder (1 pcs.) for Voluson E8 / Voluson E6 2 Y Y
202
Probe Holder for Endocavity probes
KTZ134657 Holder for Endocavity probes 1 Y Y
203
Probe Holder Kit
KTZ134697 Probe Holder Kit (inset 1-4) for Voluson E8 / Voluson E6 1 Y Y
204
Console Rubber bar 1.8m
KTZ220621
Console Rubber bar 1.8m
(sealing between Console Cover and Trolley)
1 N Y
205
Caps for TGC Sliders (R)
KTZ220870
Caps for TGC Sliders on RTU3/4/5/6 Console
(8 pieces with premounted brackets)
8 Y Y
206
Caps for TGC Sliders (W)
KTZ280223
Caps for TGC Sliders on RTU50 Console
(8 pieces with premounted brackets)
8 Y Y
207
Caps for Rotation digipots (R)
KTZ220871
Caps for Rotation digipots on RTU3/4/5/6 Console
(10 pieces with premounted brackets)
10 Y Y
208
Caps for Rotation digipots (W)
KTZ280224
Caps for Rotation digipots on RTU50 Console
(10 pieces with premounted brackets)
10 Y Y
209
Caps for Hardkeys 2 (R)
KTZ300424 all caps for hardkeys on RTU3/4/5/6 Console 1 Y Y
210
Function Key Set (W)
KTZ280225 includes all caps for hardkeys on RTU50 Console 1 Y Y
211
Caps for Keyboard keys 2 (R)
KTZ300425 all caps for alphanum. keyboard on RTU3/4/5/6 Console 1 N Y
212
Digipot Encoder (R)
KTZ220875 Digipot Encoder , 10 pcs. 10 N Y
213
Digipot Encoder (W)
KTZ280231 Digipot Encoder, 10 pcs. 10 N Y
214
Console Back Cover
KTZ134646 Console Back Cover for Voluson E8 / Voluson E6 1 N Y
215
RTU3 Console (R)
KTZ300207
Voluson E8 / Voluson E6 Console incl. English keyboard,
trackball, display, special knobs and switches
1N Y
216
RTU4 / RTU5* Console (R)
KTZ301746
Voluson E8 / Voluson E6 Console incl. English keyboard,
trackball, display, special knobs and switches
1 N Y
217
RTU6 Console (R)
KTZ302696
Voluson E8 / Voluson E6 Console incl. English keyboard,
trackball, display, special knobs and switches
1 N Y
218
RTU50 Console (W)
KTZ280226
Voluson E8 / Voluson E6 Console incl. English keyboard,
trackball, display, special knobs and switches
1 N Y
219
Console Top Cover with
Touchscreen (R)
KTZ280183
Voluson E8 / Voluson E6 Console Top Cover with premounted
Touchscreen
1N Y
220
Console Top Cover (W)
KTZ280227
Voluson E8 / Voluson E6 Console Top Cover
without Touchscreen
1N Y
221
Console Front Handle
KTZ280106
Console Front Handle for Voluson E8 / Voluson E6
2 parts (upper and bottom part)
1N Y
