Chapter 9 - Renewal Parts 9-15
NOTE: The installed Hardware configuration is shown in the System Info page (see: Figure 7-1 on page 7-3).
Table 9-10 FrontEnd (US-Part) cont´d
Item Part Name Part Number Description Qty CRU FRU
511
GBF60-62 - Beamformer Module
without Sub-boards
KTZ280089
Beamformer Assembly including Probe Control Board
(RTF) and Beamformer Motherboard (RTM);
without any Sub-boards
1NY
512
GBF65 - Beamformer Module
without Sub-boards
KTZ280172
Beamformer Assembly including Probe Control Board
(RTF) and Beamformer Motherboard (RTM);
without any Sub-boards
1NY
513
GBF80 - Beamformer Module
without Sub-boards
KTZ280090
Beamformer Assembly including Probe Control Board
(RTF) and Beamformer Motherboard (RTM);
without any Sub-boards
1NY
514
RSR14.P9* - Receiver Sub-board HAL
KTZ196357
RX Sub-board on Beamformer Motherboard RTM
(1 pcs.)
16 N Y
515
RSR19c.P16 - Receiver Sub-board
KTZ196310
RX Sub-board on Beamformer Motherboard RTM
(1 pcs.)
16 (VE8)
8 (VE6)
N Y
516
RST15.P6 - Transmitter Sub-board HAL
KTZ196358
TX Sub-board on Beamformer Motherboard RTM
(1 pcs.)
16
12
(VE6*)
N Y
517
RST20.P8 - Transmitter Sub-board
KTZ280122
TX Sub-board on Beamformer Motherboard RTM
(1 pcs.)
16
12
(VE6*)
NY
518
RSW16-17a.P4-P6 - CW-Doppler Board
KTZ196088 CW-Doppler Board, optional - N Y
* Voluson E6 BT10/BT12/BT13
