GE HEALTHCAREDRAFT VOLUSON E8 / VOLUSON E6
D
IRECTION KTD102576, REVISION 7 DRAFT (AUGUST 23, 2012) SERVICE MANUAL
Chapter 9 - Renewal Parts 9-17
Table 9-11 Back End (PC-Part) Components
Item Part Name Part Number Description Qty CRU FRU
571
ADD2-DVI card
KTZ208588 ADD2-DVI (Add-On) card for PC-Motherboard 1 N Y
572
Graphic card
KTZ280091 Graphic card for PC-Motherboard 1 N Y
573
Graphic card 2
KTZ302459 Graphic card for PC-Motherboard 1 N Y
574
Graphic card 3
KTZ280236 Graphic card for PC-Motherboard 1 N Y
575
Battery Lithium CR2032 (3V)
KTZ208791 Lithium Battery CR2032 (3V) for PC-Motherboard 1 N Y
576
Hard Disk Drive (HDD)
KTZ280092
Hard disk drive SATA 320Gbyte
(Western Digital or Seagate)
System/Boot DVD (see: Table 9-12) is required
1 N Y
577
Hard Disk Drive (HDD) BT12/BT13
KTZ302446
Hard disk drive SATA 500Gbyte
(Western Digital or Hitachi)
System/Boot DVD (see: Table 9-12) is required
1N Y
578
Fan Set (2 fan) for PC - BackEnd
KTZ134698 Fan for PC-box (2 fan) - BackEnd 1 N Y
579
Back End Processor (BEP) Kit BT09,
incl. housing and cables
KTZ280118
Kit contains ATX Motherboard “KONTRON”,
CPU cooler, 4Gbyte RAM, Serial Slot, Fan(s),
housing + internal cables premounted
1N Y
580
Back End Processor (BEP) Kit BT10,
incl. housing and cables
KTZ280171
Kit contains ATX Motherboard “KONTRON”,
CPU cooler, 4Gbyte RAM, Serial Slot, Fan(s),
housing + internal cables premounted
1 N Y
581
Back End Processor (BEP) Kit BT12/BT13,
incl. housing and cables
KTZ302178
Kit contains ATX Motherboard “ADVANTECH”,
CPU cooler, RAM, Serial Slot, Fan(s),
housing + internal cables premounted
1 N Y
582
RTB4.P6 - Distribution Board Bottom
KTZ221016 Distribution Board Bottom 1 N Y
583
RTV2a.P2 - Video Management Board
KTZ196208 Video Management Board 1 N Y
