GE Voluson E6

GE HEALTHCARERAFT VOLUSON E8 / VOLUSON E6
D
IRECTION KTD102576, REVISION 7 DRAFT (AUGUST 23, 2012) SERVICE MANUAL
9-28 Section 9-10 - Miscellaneous Cables
732
GES15 External I/O Connection Panel
KTZ196332
External Rear Panel incl. VGA, USB, Network and
S-Video cables to the Voluson system (internal)
1N Y
733
Adapter S-Video -> RCA Jack (Cinch)
KTZ196334
Adapter S-Video -> RCA Jack (Cinch)
to be used in combination with GES15
1 N Y
734
RTP-ATX Adapter
KTZ220899
ATX Adapter between RTP (Secondary Power Supply) and
PC-Motherboard (only used at Voluson E6 BT09 system if
RTP5 is installed)
1 N Y
735
VGA cable for Secondary Monitor
KTZ220527
VGA cable to connect Secondary Patient Monitor (15m)
- N Y
Table 9-13 Miscellaneous Cables
Item Part Name Part Number Description Qty CRU FRU
