gefran TPD32-EV-...-4B - Figure 5.3.6.7: Above: Flux Reference; Below: Flux Current. the Increment in the Field Current Has no Jump. Variation Compared to Fig.5.3.6.5 Increase of Flux P from 2 to 10%. Flux I = 5

—————— Instruction manual ——————
129
Figure 5.3.6.7: Above: Flux reference; Below: Flux current. The increment in
the field current has no jump. Variation compared to Fig.5.3.6.5: Increase of
Flux P from 2 to 10%. Flux I = 5%.
