gefran TPD32-EV-...-4B - Figure 6.13.3.1: Speed Threshold (Up) and Set Speed (Down) Messages

—————— Instruction manual ——————
227
0
t
0
t
Actual spd (rpm)
Threshold delay
100 ms
Spd threshold
Spd threshold +
1000 rpm
Spd threshold -
1000 rpm
Set delay
100 ms
Set speed
Set error
100 rpm
Speed ref
Actual spd (rpm)
Figure 6.13.3.1: “Speed threshold” (up) and “Set speed” (down) messages
