gefran TPD32-EV-...-4B - Figure 2.4.18: TPD32-EV-500;520-3300-4 B-E and TPD32-EV-690;720-3300-4 B-E Dimensions

—————— TPD32-EV ——————
54
Figure 2.4.18: TPD32-EV-500/520-3300-4B-E and TPD32-EV-690/720-3300-4B-E dimensions
Values in mm.
Characteristics
WEIGHT 322 kg
FAN UNIT Tot. capacity 2600 m
3
/h
Single-phase motor 230 V 50/60 Hz 1 A tot. 71÷74dBA
