gefran TPD32-EV-...-4B - Figure 6.17.11: Coil Stop after the Automatic Switching; Jog Function

—————— TPD32-EV ——————
342
Diam calc Dis
Start (drive)
Torque winder en
Speed=0
Figure 6.17.11: Coil stop after the automatic switching
Jog function
Thissequenceisusedinparticularonunwindersinordertobringthecoilmaterialtilltherstniproll.
+
-
W reference
Winder side
Start (drive)
Jog TWenable
Diam calc Dis
Diam reset
Figure 6.17.12: Jog function to prepare the machine
 Initializethediametervalueasstatedabove.
 Disablethediametercalculation. EnableJog TW enable.
 UsetheStart/stopcommandtocarryouttheJogfunction.
 WiththeStartthemotorincreasesthecoilspeedtillreachingtheperipheralspeedsetinJog TW speedwith
theramptimeSpd match acc.
 WiththeStopthemotordecreasesitsspeedtillreachingthe0speedwiththeramptimeSpd match dec.
 InordertochangetherotationdirectionusethecommandWinder side.
