—————— Instruction manual ——————

4.10.2 Interference suppression filters

TheconvertersofTPD32-EVseriesmustbeequippedwithanexternalEMIlterinordertoreducetheradi-

ofrequencyemissionsonthemainsline.Thelterselectionisdependingonthedrivesizeandtheinstallation

environment.

PleaserefertotheEMCguidesuppliedwiththeequipmentfordetailsofhowtoinstalltheelectricalpanel

(connectionofltersandmainschokes,cableshielding,grounding,etc.)toensurecompliancewiththeEMC

Directive(2014/30/EC).

ThedocumentdescribesthepresentsituationconcerningtheEMCstandardsandthecompliancetestsmadeon

theGefrandrives.

Table 4.10.2: EMI filters

TPD32 EV

Standard sizes

TPD32 EV

Standard sizes

Filter type Code

Dimensions:

W x H x d

[mm]

Weight

[kg]

Category / Environ-

ment / Length of

motor cable (max)

Mains voltage 230-400 V ± 10%

TPD32-EV-500/600-20-2B-A TPD32-EV-500/520-20-4B-A EMI-480-45 S7DFU 250x85x90 1.3 C3 / 2° / 30 m

TPD32-EV-500/600-40-2B-A TPD32-EV-500/520-40-4B-A EMI-480-45 S7DFU 250x85x90 1.3 C3 / 2° / 30 m

TPD32-EV-500/600-70-2B-A TPD32-EV-500/520-70-4B-A EMI-480-70 S7DFZ 270x90x150 2.6 C3 / 2° / 30 m

TPD32-EV-500/600-110-2B-A TPD32-EV-500/520-110-4B-A EMI-480-100 S7DGA 270x90x150 2.6 C3 / 2° / 30 m

TPD32-EV-500/600-140-2B-A TPD32-EV-500/520-140-4B-A EMI-480-150 S7DGB 400x120x170 4.4 C3 / 2° / 30 m

TPD32-EV-500/600-185-2B-A TPD32-EV-500/520-185-4B-A EMI-480-180 S7DGC 400x120x170 4.4 C3 / 2° / 30 m

TPD32-EV-500/600-280-2B-B TPD32-EV-500/520-280-4B-B EMI-480-320 S7DGH 300x260x135 13.2 C3 / 2° / 100 m

TPD32-EV-500/600-350-2B-B TPD32-EV-500/520-350-4B-B EMI-480-400 S7DGI 300x260x135 13.4 C3 / 2° / 100 m

TPD32-EV-500/600-420-2B-B TPD32-EV-500/520-420-4B-B EMI-480-400 S7DGI 300x260x135 13.4 C3 / 2° / 100 m

TPD32-EV-500/600-500-2B-B TPD32-EV-500/520-500-4B-B EMI-480-600 S7DGL 300x260x135 13.6 C3 / 2° / 100 m

TPD32-EV-500/600-650-2B-B TPD32-EV-500/520-650-4B-B EMI-480-800 S7DGM 350x280x150 23 C3 / 2° / 100 m

TPD32-EV-500/600-770-2B-C TPD32-EV-500/520-770-4B-C EMI-480-800 S7DGM 350x280x150 23 C3 / 2° / 100 m

TPD32-EV-500/600-1000-2B-C TPD32-EV-500/520-1050-4B-C EMI-480-1000 S7DGN 350x280x150 24 C3 / 2° / 100 m

TPD32-EV-500/600-1400-2B-D TPD32-EV-500/520-1400-4B-D EMI-480-1600 S7DGO 400x300x160 34 C3 / 2° / 100 m

TPD32-EV-500/600-1600-2B-D TPD32-EV-500/520-1600-4B-D EMI-480-1600 S7DGO 400x300x160 34 C3 / 2° / 100 m

TPD32-EV-500/600-2000-2B-D TPD32-EV-500/520-2000-4B-D EMI-FN-3359-480-2500 S7EMI5 600x370x200 55 C3 / 2° / 100 m

TPD32-EV-500/600-2400-2B-D TPD32-EV-500/520-2400-4B-D EMI-FN-3359-480-2500 S7EMI5 600x370x200 55 C3 / 2° / 100 m

TPD32-EV-500/600-1200-2B-E ----- EMI-480-1600 S7DGO 400x300x160 34 C3 / 2° / 100 m

TPD32-EV-500/600-1500-2B-E TPD32-EV-500/520-1500-4B-E EMI-480-1600 S7DGO 400x300x160 34 C3 / 2° / 100 m

TPD32-EV-500/600-1800-2B-E TPD32-EV-500/520-1700-4B-E EMI-FN-3359-480-2500 S7EMI5 600x370x200 55 C3 / 2° / 100 m

TPD32-EV-500/600-2000-2B-E TPD32-EV-500/520-2000-4B-E EMI-FN-3359-480-2500 S7EMI5 600x370x200 55 C3 / 2° / 100 m

TPD32-EV-500/600-2400-2B-E TPD32-EV-500/520-2400-4B-E EMI-FN-3359-480-2500 S7EMI5 600x370x200 55 C3 / 2° / 100 m

TPD32-EV-500/600-2700-2B-E TPD32-EV-500/520-2700-4B-E EMI-FN-3359-480-2500 S7EMI5 600x370x200 55 C3 / 2° / 100 m

TPD32-EV-500/600-2900-2B-E ----- n.d.

TPD32-EV-500/600-3300-2B-E TPD32-EV-500/520-3300-4B-E n.d.

Mains voltage 480 V ± 10%
