Table 4.4.6 - A: Terminal Assignment (terminals from 1 to 20)
Terminal designation Function I/O Max voltage Max current
1 +2 Configurable analog differntial input
I ±10V
0.25mA
Analog input 1 Signal: Term. 1, Reference point Term. 2 (20mA at current
Factory set for Ramp ref 1* ref. value)
3 +4 Configurable analog differntial input
I ±10V
0.25mA
Analog input 2 Signal: Term. 3, Reference point Term. 4 (20mA at current
Not factory set ref. value)
5 +6 Configurable analog differntial input
I ±10V
0.25mA
Analog input 3 Signal: Term. 5, Reference point Term. 6 (20mA at current
Not factory set ref. value)
7 Reference voltage +10V
O +10V 10mA
+10V Reference point: Term. 9
8 Reference voltage -10V
O -10V 10mA
-10V Reference point: Term. 9
9 Reference point for the reference voltages on
— — —
0V 10 terminal 7 and 8
10 Screen connection (PE) (connected with housing) — — —
11 Internal 0V — — —
12 Converter enable
I +30V
15V/3,2mA
Enable drive 0V Disabled converter 24V/5mA
+15...30V Enabled converter 30V/6,4mA
13 Start command
I +30V
15V/3,2mA
Start 0V No start command 24V/5mA
+15...30V Start 30V/6,4mA
14 Fast stop
I +30V
15V/3,2mA
Fast stop 0V Fast stop 24V/5mA
+15...30V No Fast stop 30V/6,4mA
15 External fault
I +30V
15V/3,2mA
External fault 0V External fault present 24V/5mA
+15...30V No external fault present 30V/6,4mA
16 Reference point of the digital inputs,
— — —
COM ID terminals 12 to 15
18 Reference point of the 24V voltage
— — —
0V 24 on terminal 19
19 Voltage +24V
O +20...30V 200 mA**
+24 V Reference point Terminal 18
20 Screen connection (PE) (connected w/housing) — — —
* Theusercanadaptthecongurationtotherequirementsoftheapplicationconcernedviathekeypad,theserialinterfaceorabusconnection.
** TotalvalueincludingTerminal19,Pin2ofconnectorXE2andthedigitaloutputsontheTBOoptioncard.
TheR-TPD32-EVregulationcardincludesaTBOcard(terminals21to42).Theintegratedcardisconsidered
bythedeviceasTBO“A”.
Table 4.4.6 - B: Terminal Assignment (terminals from 21 to 42)
Designation Function I/O Max voltage Max current
21
Analog out 1
Analog output 1
Reference point: Terminal 22
Factory set for Actual speed
O ±10V 5mA
22
COM analog output 1
Reference point of analog output 1 — — —
23
Analog out 2
Analog output 2
Reference point: Terminal 24
Factory set for Motor current
O ±10V 5mA
