—————— TPD32-EV ——————
338
Digital outputs
1
2
34
Supply
Digital inputs
1 234 5 6789 10 15 11 12 13 14
1
2
34
18
19
0 V 24
+ 24 V
0 V
+ 24 V
TBO
DRIVE REGULATION BOARD
Analog outputs
1
2
Motor current -10...0...+10V
Roll diameter 0...10V
0V
I/O expansion card on TPD32-EV winder motor (connector XBA)
Diam preset sel
2
Diam preset sel
1
Diam reset
T
orque winder En
Diameter reached + 24V
Figure 6.17.7: Winder with an automatic switch and a closed loop tension regulation
(I/O expansion card)
