gefran TPD32-EV-...-4B - Table 2.5.2: Dissipated Power TPD32-EV-CU Series

—————— Instruction manual ——————
57
Moidel
Dissipated power
Total for control unit External field fuses
[W] [W]
TPD32-EV-CU-230/500-THY1-40
TPD32-EV-CU-230/500-THY2-40
303 2 x 11
TPD32-EV-CU-230/500-THY1-70
TPD32-EV-CU-230/500-THY2-70
357 2 x 14
TPD32-EV-CU-575/690-THY1-40
TPD32-EV-CU-575/690-THY2-40
374 2 x 11
TPD32-EV-CU-575/690-THY1-70
TPD32-EV-CU-575/690-THY2-70
428 2 x 14
Table 2.5.2: Dissipated power TPD32-EV-CU series
Informationonthepowerdissipatedbyrecommendedexternaleldfusesisalsoprovided.
