6.14.7 Stop control
FUNCTIONS
Stop control
[626] Stopmode
[627] Spd0tripdelay[ms]
[628] Tripcontdelay[ms]
[630] Jogstopcontrol
ThisfunctionisintendedtohelpthesystemengineertocoordinatetheACinputcontactorwiththedriveenabling.
Accordingtotheselectedmodetheterminals75and76drivetheON/OFFoftheACinputcontactor.
Basically,whenthedrivereceivestheStartcommandtheRelay2closestheACinputcontactor,thedrivewaits
foracertaintimetheACinputvoltage,syncronizesitselfandstartsthemotor.Whenthedrivestops,themo-
torgoestozerospeed.Whenthezerospeedisreached,thedriveisdisabledonlywhena“Spd0trip”delayis
elapsed.Thenafterthe“Tripcontdelay”theRelay2openstoremovethesupplyfromthedrive.
Parameter description No.
Value
Standard
Conguration
min max
Factory
American
Factory
Standard
Stop mode
OFF(0)
Stop&speed0(1)
Faststp&spd0(2)
Fst/stp&spd0(3)
626 0 3 Stop&Speed0 Stop&Speed0
*
Relay75/76
Spd 0 trip delay [ms]
627 0 40000 0 0
-
Trip cont delay [ms]
628 0 40000 0 0
-
Jog stop control
OFF(0)
ON(1)
630 0 1 OFF OFF
-
Figure 6.14.7.1: Start and stop management
Stop mode OFF Thefunctionisdisabled.
 Stop&Speed0 TheStartcommanddeterminesthebehavior.IftheStartcom-
mandisnotpresent(digitalorviaterminalstrip)andthedriveis
stopped,theconverterisblockedandthecontactisopen.When
theStartcommandisgiven,theconverterisenabledandthe
contactisclosed.DisablingtheStartcommandandafterreaching
