6.14.4 Multi ramp function
FUNCTIONS
Multi ramp fct
[243] Enabmultirmp
[202] Rampselector
Multi ramp fct
Ramp 0
Acceleration 0
[659] Accdeltaspeed0[FF]
[660] Accdeltatime0[s]
[665] Sacctconst0[ms]
Deceleration 0
[661] Decdeltaspeed0[FF]
[662] Decdeltatime0[s]
[666] Sdectconst0[ms]
Ramp 1
Acceleration 1
[23] Accdeltaspeed1[FF]
[24] Accdeltatime1[s]
[667] Sacctconst1[ms]
Deceleration 1
[31] Decdeltaspeed1[FF]
[32] Decdeltatime1[s]
[668] Sdectconst1[ms]
Ramp 2
Acceleration 2
[25] Accdeltaspeed2[FF]
[26] Accdeltatime2[s]
[669] Sacctconst2[ms]
Deceleration 2
[33] Decdeltaspeed2[FF]
[34] Decdeltatime2[s]
[670] Sdectconst2[ms]
Ramp 3
Acceleration 3
[27] Accdeltaspeed3[FF]
[28] Accdeltatime3[s]
[671] Sacctconst3[ms]
Deceleration 3
[35] Decdeltaspeed3[FF]
[36] Decdeltatime3[s]
[672] Sdectconst3[ms]
TheMultirampfunctionenablesuptofourdifferentrampstobecalledup.Theaccelerationanddeceleration
timescanalsobedenedhereseparately.Therampsarecalledupviadigitalsignals.
