6.14 FUNCTIONS
6.14.1 Motorpotentiometer
FUNCTIONS
Motor pot
[246] Enablemotorpot
[247] Motorpotoper
[248] Motorpotsign
[249] Motorpotreset
[1530] MPotLowerLimit[rpm]
[1531] MPotUpperLimit[rpm]
[1532] MPotAccTime[s]
[1533] MPotDecTime[s]
[1534] MPotMode
[1535] PowerOnCfg
[1536] ResetCfg
[1537] Motorpotout[rpm]
Themotorpotentiometerfunctionallowsthespeedofthedrivetobeadjustedbyusingthe+/-keysonthe
keypadorbydigitalinputs.Thespeedisthenadjustedaccordingtothedeedramptime.
Parameter description No.
Value
Standard
Conguration
min max
Factory
American
Factory
Standard
Enable motor pot
Disabled(0);Cong1(1);Cong2(2)
246 0 1 Disabled Disabled -
Motor pot oper
247 -
Motor pot sign
Positive(1)/Negative(0)
248 0 1 Positive Positive -
Motor pot sign +
- **
Motor pot sign -
- **
Motor pot reset
249 *
Motor pot up
Noacceleration(0)
Acceleration(1)
396 0 1 *
Motor pot down
Nodeceleration(0)
Deceleration(1)
397 0 1 *
MPot Lower Limit
1530 0 8000 0 0
MPot Upper Limit
1531 0 8000 1000 1000
MPot Acc Time
1532 0 65535 10 10
MPot Dec Time
1533 0 65535 10 10
MPot Mode
Ramp&LastVal(0)
 Ramp&Follow(1)
 Fine&LastVal(2)
 Fine&Follow(3)
1534 0 0
PowerOn Cfg
LastPowerOff(0)
Zero(1)
LowerLimit(2)
UpperLimit(3)
1535 0 0
Reset Cfg
None(0)
InpZero(1)
InpLowLimit(2)
InpRefZero(3)
InpRefLowLim(4)
OutZero(5)
OutLowLimit(6)
OutRefZero(7)
OutRefLowLim(8)
InpUpLimit(9)
InpRefUpLim(10)
InpFreeze(11)
1536
Motor pot out
1537
*Thisfunctioncanbeassignedtooneoftheprogrammabledigitalinputs.
** Thisparametercanbeassignedtoaprogrammableanalogoutput.
