gefran TPD32-EV-...-4B - Figure 2.4.2: Type A2 Dimensions

—————— Instruction manual ——————
37
Figure 2.4.2: Type A2 dimensions
250mm [9.84”]
42.75mm 275mm [10.8”] 23.25mm
266.8mm [10.5”]
263.2mm [2.3”]
279.9mm [11.02”]
7mm
237.2mm [9.34”]
349.1mm [11.74”]
American Standard Weight
kg [lbs]
TPD32-EV-.../...-56-..-A TPD32-EV-.../...-70-..-A 8.8[19.4]
