—————— TPD32-EV ——————
100
TPD32 EV
Standard sizes
TPD32 EV
Standard sizes
Filter type Code
Dimensions:
W x H x d
[mm]
Weight
[kg]
Category / Environ-
ment / Length of
motor cable (max)
TPD32-EV-500/600-770-2B-C TPD32-EV-500/520-770-4B-C EMI-480-800 S7DGM 350x280x150 23 C3 / 2° / 100 m
TPD32-EV-500/600-1000-2B-C TPD32-EV-500/520-1050-4B-C EMI-480-1000 S7DGN 350x280x150 24 C3 / 2° / 100 m
TPD32-EV-500/600-1400-2B-D TPD32-EV-500/520-1400-4B-D EMI-480-1600 S7DGO 400x300x160 34 C3 / 2° / 100 m
TPD32-EV-500/600-1600-2B-D TPD32-EV-500/520-1600-4B-D EMI-480-1600 S7DGO 400x300x160 34 C3 / 2° / 100 m
TPD32-EV-500/600-2000-2B-D TPD32-EV-500/520-2000-4B-D EMI-FN-3359-480-2500 S7EMI5 600x370x200 55 C3 / 2° / 100 m
TPD32-EV-500/600-2400-2B-D TPD32-EV-500/520-2400-4B-D EMI-FN-3359-480-2500 S7EMI5 600x370x200 55 C3 / 2° / 100 m
TPD32-EV-500/600-1200-2B-E ----- EMI-480-1600 S7DGO 400x300x160 34 C3 / 2° / 100 m
TPD32-EV-500/600-1500-2B-E TPD32-EV-500/520-1500-4B-E EMI-480-1600 S7DGO 400x300x160 34 C3 / 2° / 100 m
TPD32-EV-500/600-1800-2B-E TPD32-EV-500/520-1700-4B-E EMI-FN-3359-480-2500 S7EMI5 600x370x200 55 C3 / 2° / 100 m
TPD32-EV-500/600-2000-2B-E TPD32-EV-500/520-2000-4B-E EMI-FN-3359-480-2500 S7EMI5 600x370x200 55 C3 / 2° / 100 m
TPD32-EV-500/600-2400-2B-E TPD32-EV-500/520-2400-4B-E EMI-FN-3359-480-2500 S7EMI5 600x370x200 55 C3 / 2° / 100 m
TPD32-EV-500/600-2700-2B-E TPD32-EV-500/520-2700-4B-E EMI-FN-3359-480-2500 S7EMI5 600x370x200 55 C3 / 2° / 100 m
TPD32-EV-500/600-2900-2B-E ----- n.d.
TPD32-EV-500/600-3300-2B-E TPD32-EV-500/520-3300-4B-E n.d.
Mains voltage 500 V ± 10%
TPD32-EV-500/600-20-2B-A TPD32-EV-500/520-20-4B-A EMI-600-34 S7DFM 335x60x150 1.8 C3 / 2° / 30 m
TPD32-EV-500/600-40-2B-A TPD32-EV-500/520-40-4B-A EMI-600-34 S7DFM 335x60x150 1.8 C3 / 2° / 30 m
TPD32-EV-500/600-70-2B-A TPD32-EV-500/520-70-4B-A EMI-600-62 S7DFO 329x80x125 3 C3 / 2° / 30 m
TPD32-EV-500/600-110-2B-A TPD32-EV-500/520-110-4B-A EMI-600-113 S7DFQ 379x90x220 5.6 C3 / 2° / 30 m
TPD32-EV-500/600-140-2B-A TPD32-EV-500/520-140-4B-A EMI-600-145 S7DFR 469x110x240 7.1 C3 / 2° / 30 m
TPD32-EV-500/600-185-2B-A TPD32-EV-500/520-185-4B-A EMI-SCHF-600-205 S7DGD 420x210x127 6.5 C3 / 2° / 30 m
TPD32-EV-500/600-280-2B-B TPD32-EV-500/520-280-4B-B EMI-690-320 S7DGR 230x190x116 7.2 C3 / 2° / 100 m
TPD32-EV-500/600-350-2B-B TPD32-EV-500/520-350-4B-B EMI-690-400
S7EMI12
230x190x116 7.5 C3 / 2° / 100 m
TPD32-EV-500/600-420-2B-B TPD32-EV-500/520-420-4B-B EMI-690-400
S7EMI12
230x190x116 7.5 C3 / 2° / 100 m
TPD32-EV-500/600-500-2B-B TPD32-EV-500/520-500-4B-B EMI-690-600 S7DGS 230x190x116 7.8 C3 / 2° / 100 m
TPD32-EV-500/600-650-2B-B TPD32-EV-500/520-650-4B-B EMI-690-600 S7DGS 230x190x116 7.8 C3 / 2° / 100 m
TPD32-EV-500/600-770-2B-C TPD32-EV-500/520-770-4B-C EMI-690-1000 S7DGT 300x260x140 18.5 C3 / 2° / 100 m
TPD32-EV-500/600-1000-2B-C TPD32-EV-500/520-1050-4B-C EMI-690-1000 S7DGT 300x260x140 18.5 C3 / 2° / 100 m
TPD32-EV-500/600-1400-2B-D TPD32-EV-500/520-1400-4B-D EMI-690-1600 S7DGK 300x260x140 24.5 C3 / 2° / 100 m
TPD32-EV-500/600-1600-2B-D TPD32-EV-500/520-1600-4B-D EMI-690-1600 S7DGK 300x260x140 24.5 C3 / 2° / 100 m
TPD32-EV-500/600-2000-2B-D TPD32-EV-500/520-2000-4B-D Schaffner FN 3359HV-
2500-99 (or EPCOS
B84143B2500S024)
600x370x200
(650x320x221.5)
55
(105)
C3 / 2° / 100 m
TPD32-EV-500/600-2400-2B-D TPD32-EV-500/520-2400-4B-D
TPD32-EV-500/600-1200-2B-E ----- EMI-690-1000 S7DGT 300x260x140 18.5 C3 / 2° / 100 m
TPD32-EV-500/600-1500-2B-E TPD32-EV-500/520-1500-4B-E EMI-690-1600 S7DGK 300x260x140 24.5 C3 / 2° / 100 m
TPD32-EV-500/600-1800-2B-E TPD32-EV-500/520-1700-4B-E
Schaffner FN 3359HV-
2500-99 (or EPCOS
B84143B2500S024)
600x370x200
(650x320x221.5)
55
(105)
C3 / 2° / 100 m
TPD32-EV-500/600-2000-2B-E TPD32-EV-500/520-2000-4B-E
TPD32-EV-500/600-2400-2B-E TPD32-EV-500/520-2400-4B-E
TPD32-EV-500/600-2700-2B-E TPD32-EV-500/520-2700-4B-E
TPD32-EV-500/600-2900-2B-E ----- n.d.
TPD32-EV-500/600-3300-2B-E TPD32-EV-500/520-3300-4B-E n.d.
Mains voltage 575 V ± 10%
TPD32-EV-500/600-20-2B-A TPD32-EV-500/520-20-4B-A EMI-600-34 S7DFM 335x60x150 1.8 C3 / 2° / 30 m
TPD32-EV-500/600-40-2B-A TPD32-EV-500/520-40-4B-A EMI-600-34 S7DFM 335x60x150 1.8 C3 / 2° / 30 m
TPD32-EV-500/600-70-2B-A TPD32-EV-500/520-70-4B-A EMI-600-62 S7DFO 329x80x125 3 C3 / 2° / 30 m
TPD32-EV-500/600-110-2B-A TPD32-EV-500/520-110-4B-A EMI-600-113 S7DFQ 379x90x220 5.6 C3 / 2° / 30 m
TPD32-EV-500/600-140-2B-A TPD32-EV-500/520-140-4B-A EMI-600-145 S7DFR 469x110x240 7.1 C3 / 2° / 30 m
TPD32-EV-500/600-185-2B-A TPD32-EV-500/520-185-4B-A EMI-SCHF-600-205 S7DGD 420x210x127 6.5 C3 / 2° / 30 m
TPD32-EV-500/600-280-2B-B TPD32-EV-500/520-280-4B-B EMI-690-320 S7DGR 230x190x116 7.2 C3 / 2° / 100 m
TPD32-EV-500/600-350-2B-B TPD32-EV-500/520-350-4B-B EMI-690-400
S7EMI12
230x190x116 7.5 C3 / 2° / 100 m
TPD32-EV-500/600-420-2B-B TPD32-EV-500/520-420-4B-B EMI-690-400
S7EMI12
230x190x116 7.5 C3 / 2° / 100 m
