—————— Instruction manual ——————
101
TPD32 EV
Standard sizes
TPD32 EV
Standard sizes
Filter type Code
Dimensions:
W x H x d
[mm]
Weight
[kg]
Category / Environ-
ment / Length of
motor cable (max)
TPD32-EV-500/600-500-2B-B TPD32-EV-500/520-500-4B-B EMI-690-600 S7DGS 230x190x116 7.8 C3 / 2° / 100 m
TPD32-EV-500/600-650-2B-B TPD32-EV-500/520-650-4B-B EMI-690-600 S7DGS 230x190x116 7.8 C3 / 2° / 100 m
TPD32-EV-500/600-770-2B-C TPD32-EV-500/520-770-4B-C EMI-690-1000 S7DGT 300x260x140 18.5 C3 / 2° / 100 m
TPD32-EV-500/600-1000-2B-C TPD32-EV-500/520-1050-4B-C EMI-690-1000 S7DGT 300x260x140 18.5 C3 / 2° / 100 m
TPD32-EV-500/600-1400-2B-D TPD32-EV-500/520-1400-4B-D EMI-690-1600 S7DGK 300x260x140 24.5 C3 / 2° / 100 m
TPD32-EV-500/600-1600-2B-D TPD32-EV-500/520-1600-4B-D EMI-690-1600 S7DGK 300x260x140 24.5 C3 / 2° / 100 m
TPD32-EV-500/600-2000-2B-D TPD32-EV-500/520-2000-4B-D Schaffner FN 3359HV-
2500-99 (or EPCOS
B84143B2500S024)
600x370x200
(650x320x221.5)
55
(105)
C3 / 2° / 100 m
TPD32-EV-500/600-2400-2B-D TPD32-EV-500/520-2400-4B-D
TPD32-EV-500/600-1200-2B-E ----- EMI-690-1000 S7DGT 300x260x140 18.5 C3 / 2° / 100 m
TPD32-EV-500/600-1500-2B-E TPD32-EV-500/520-1500-4B-E EMI-690-1600 S7DGK 300x260x140 24.5 C3 / 2° / 100 m
TPD32-EV-500/600-1800-2B-E TPD32-EV-500/520-1700-4B-E
Schaffner FN 3359HV-
2500-99 (or EPCOS
B84143B2500S024)
600x370x200
(650x320x221.5)
55
(105)
C3 / 2° / 100 m
TPD32-EV-500/600-2000-2B-E TPD32-EV-500/520-2000-4B-E
TPD32-EV-500/600-2400-2B-E TPD32-EV-500/520-2400-4B-E
TPD32-EV-500/600-2700-2B-E TPD32-EV-500/520-2700-4B-E
TPD32-EV-500/600-2900-2B-E ----- n.d.
TPD32-EV-500/600-3300-2B-E TPD32-EV-500/520-3300-4B-E n.d.
Mains voltage 690 V ± 10%
TPD32-EV-690/810-560-2B-C TPD32-EV-690/720-560-4B-C EMI-690-600 S7DGS 230x190x116 7.8 C3 / 2° / 100 m
TPD32-EV-690/810-700-2B-C TPD32-EV-690/720-700-4B-C EMI-690-1000 S7DGT 300x260x140 18.5 C3 / 2° / 100 m
TPD32-EV-690/810-900-2B-C TPD32-EV-690/720-900-4B-C EMI-690-1000 S7DGT 300x260x140 18.5 C3 / 2° / 100 m
TPD32-EV-690/810-1300-2B-D TPD32-EV-690/720-1300-4B-D EMI-690-1600 S7DGK 300x260x140 24.5 C3 / 2° / 100 m
TPD32-EV-690/810-1600-2B-D TPD32-EV-690/720-1600-4B-D EMI-690-1600 S7DGK 300x260x140 24.5 C3 / 2° / 100 m
TPD32-EV-690/810-1900-2B-D TPD32-EV-690/720-1900-4B-D
EPCOS
B84143B2500S021
650x385x221.5
105 C3 / 2° / 100 m
TPD32-EV-690/810-2100-2B-D TPD32-EV-690/720-2100-4B-D
TPD32-EV-690/810-1010-2B-E TPD32-EV-690/720-1010-4B-E EMI-690-1000 S7DGT 300x260x140 18.5 C3 / 2° / 100 m
TPD32-EV-690/810-1400-2B-E TPD32-EV-690/720-1400-4B-E EMI-690-1600 S7DGK 300x260x140 24.5 C3 / 2° / 100 m
TPD32-EV-690/810-1700-2B-E TPD32-EV-690/720-1700-4B-E
EPCOS
B84143B2500S021
650x385x221.5
105 C3 / 2° / 100 m
TPD32-EV-690/810-2000-2B-E TPD32-EV-690/720-2000-4B-E
TPD32-EV-690/810-2400-2B-E TPD32-EV-690/720-2400-4B-E
TPD32-EV-690/810-2700-2B-E TPD32-EV-690/720-2700-4B-E
TPD32-EV-690/810-3300-2B-E TPD32-EV-690/720-3300-4B-E n.d.
TPD32 EV
American sizes
TPD32 EV
American sizes
Filter type Code
Dimensions:
W x H x d
[mm]
Weight
[kg]
Category / Environment
/ Length of motor cable
(max)
Mains voltage 230-400 V ± 10%
TPD32-EV-500/600-17-2B-A-NA TPD32-EV-500/520-17-4B-A-NA EMI-480-45 S7DFU 250x85x90 1.3 C3 / 2° / 30 m
TPD32-EV-500/600-35-2B-A-NA TPD32-EV-500/520-35-4B-A-NA EMI-480-45 S7DFU 250x85x90 1.3 C3 / 2° / 30 m
TPD32-EV-500/600-56-2B-A-NA TPD32-EV-500/520-56-4B-A-NA EMI-480-70 S7DFZ 270x90x150 2.6 C3 / 2° / 30 m
TPD32-EV-500/600-88-2B-A-NA TPD32-EV-500/520-88-4B-A-NA EMI-480-150 S7DGB
400x120x170
4.4 C3 / 2° / 30 m
TPD32-EV-500/600-112-2B-A-NA TPD32-EV-500/520-112-4B-A-NA EMI-480-150 S7DGB
400x120x170
4.4 C3 / 2° / 30 m
TPD32-EV-500/600-148-2B-A-NA TPD32-EV-500/520-148-4B-A-NA EMI-480-180 S7DGC
400x120x170
4.4 C3 / 2° / 30 m
TPD32-EV-500/600-224-2B-B-NA TPD32-EV-500/520-224-4B-B-NA EMI-480-320 S7DGH
300x260x135
13.2 C3 / 2° / 100 m
TPD32-EV-500/600-280-2B-B-NA TPD32-EV-500/520-280-4B-B-NA EMI-480-400 S7DGI
300x260x135
13.4 C3 / 2° / 100 m
TPD32-EV-500/600-336-2B-B-NA TPD32-EV-500/520-336-4B-B-NA EMI-480-400 S7DGI
300x260x135
13.4 C3 / 2° / 100 m
TPD32-EV-500/600-400-2B-B-NA TPD32-EV-500/520-400-4B-B-NA EMI-480-600 S7DGL
300x260x135
13.6 C3 / 2° / 100 m
TPD32-EV-500/600-450-2B-B-NA TPD32-EV-500/520-450-4B-B-NA EMI-480-600 S7DGL
300x260x135
13.6 C3 / 2° / 100 m
TPD32-EV-500/600-560-2B-C-NA TPD32-EV-500/520-560-4B-C-NA EMI-480-800 S7DGM
350x280x150
23 C3 / 2° / 100 m
