—————— TPD32-EV ——————
102
TPD32 EV
American sizes
TPD32 EV
American sizes
Filter type Code
Dimensions:
W x H x d
[mm]
Weight
[kg]
Category / Environment
/ Length of motor cable
(max)
TPD32-EV-500/600-800-2B-C-NA TPD32-EV-500/520-850-4B-C-NA EMI-480-1000 S7DGN
350x280x150
24 C3 / 2° / 100 m
TPD32-EV-500/600-1000-2B-D-NA TPD32-EV-500/520-1000-4B-D-NA EMI-480-1600 S7DGO
400x300x160
34 C3 / 2° / 100 m
TPD32-EV-500/600-1200-2B-D-NA TPD32-EV-500/520-1200-4B-D-NA EMI-480-1600 S7DGO
400x300x160
34 C3 / 2° / 100 m
TPD32-EV-500/600-1500-2B-D-NA TPD32-EV-500/520-1500-4B-D-NA EMI-FN-3359-480-2500 S7EMI5
600x370x200
55 C3 / 2° / 100 m
TPD32-EV-500/600-1850-2B-D-NA TPD32-EV-500/520-1850-4B-D-NA EMI-FN-3359-480-2500 S7EMI5
600x370x200
55 C3 / 2° / 100 m
TPD32-EV-500/600-1000-2B-E-NA ----- EMI-480-1600 S7DGO
400x300x160
34 C3 / 2° / 100 m
TPD32-EV-500/600-1300-2B-E-NA TPD32-EV-500/520-1300-4B-E-NA EMI-480-1600 S7DGO
400x300x160
34 C3 / 2° / 100 m
TPD32-EV-500/600-1400-2B-E-NA TPD32-EV-500/520-1350-4B-E-NA EMI-FN-3359-480-2500 S7EMI5
600x370x200
55 C3 / 2° / 100 m
TPD32-EV-500/600-1500-2B-E-NA TPD32-EV-500/520-1500-4B-E-NA EMI-FN-3359-480-2500 S7EMI5
600x370x200
55 C3 / 2° / 100 m
TPD32-EV-500/600-1800-2B-E-NA TPD32-EV-500/520-1800-4B-E-NA EMI-FN-3359-480-2500 S7EMI5
600x370x200
55 C3 / 2° / 100 m
TPD32-EV-500/600-2000-2B-E-NA TPD32-EV-500/520-2000-4B-E-NA EMI-FN-3359-480-2500 S7EMI5
600x370x200
55 C3 / 2° / 100 m
TPD32-EV-500/600-2200-2B-E-NA ----- n.d.
TPD32-EV-500/600-2350-2B-E-NA TPD32-EV-500/520-2350-4B-E-NA n.d.
Mains voltage 480 V ± 10%
TPD32-EV-500/600-17-2B-A-NA TPD32-EV-500/520-17-4B-A-NA EMI-480-45 S7DFU 250x85x90 1.3 C3 / 2° / 30 m
TPD32-EV-500/600-35-2B-A-NA TPD32-EV-500/520-35-4B-A-NA EMI-480-45 S7DFU 250x85x90 1.3 C3 / 2° / 30 m
TPD32-EV-500/600-56-2B-A-NA TPD32-EV-500/520-56-4B-A-NA EMI-480-70 S7DFZ 270x90x150 2.6 C3 / 2° / 30 m
TPD32-EV-500/600-88-2B-A-NA TPD32-EV-500/520-88-4B-A-NA EMI-480-150 S7DGB
400x120x170
4.4 C3 / 2° / 30 m
TPD32-EV-500/600-112-2B-A-NA TPD32-EV-500/520-112-4B-A-NA EMI-480-150 S7DGB
400x120x170
4.4 C3 / 2° / 30 m
TPD32-EV-500/600-148-2B-A-NA TPD32-EV-500/520-148-4B-A-NA EMI-480-180 S7DGC
400x120x170
4.4 C3 / 2° / 30 m
TPD32-EV-500/600-224-2B-B-NA TPD32-EV-500/520-224-4B-B-NA EMI-480-320 S7DGH
300x260x135
13.2 C3 / 2° / 100 m
TPD32-EV-500/600-280-2B-B-NA TPD32-EV-500/520-280-4B-B-NA EMI-480-400 S7DGI
300x260x135
13.4 C3 / 2° / 100 m
TPD32-EV-500/600-336-2B-B-NA TPD32-EV-500/520-336-4B-B-NA EMI-480-400 S7DGI
300x260x135
13.4 C3 / 2° / 100 m
TPD32-EV-500/600-400-2B-B-NA TPD32-EV-500/520-400-4B-B-NA EMI-480-600 S7DGL
300x260x135
13.6 C3 / 2° / 100 m
TPD32-EV-500/600-450-2B-B-NA TPD32-EV-500/520-450-4B-B-NA EMI-480-600 S7DGL
300x260x135
13.6 C3 / 2° / 100 m
TPD32-EV-500/600-560-2B-C-NA TPD32-EV-500/520-560-4B-C-NA EMI-480-800 S7DGM
350x280x150
23 C3 / 2° / 100 m
TPD32-EV-500/600-800-2B-C-NA TPD32-EV-500/520-850-4B-C-NA EMI-480-1000 S7DGN
350x280x150
24 C3 / 2° / 100 m
TPD32-EV-500/600-1000-2B-D-NA TPD32-EV-500/520-1000-4B-D-NA EMI-480-1600 S7DGO
400x300x160
34 C3 / 2° / 100 m
TPD32-EV-500/600-1200-2B-D-NA TPD32-EV-500/520-1200-4B-D-NA EMI-480-1600 S7DGO
400x300x160
34 C3 / 2° / 100 m
TPD32-EV-500/600-1500-2B-D-NA TPD32-EV-500/520-1500-4B-D-NA EMI-FN-3359-480-2500 S7EMI5
600x370x200
55 C3 / 2° / 100 m
TPD32-EV-500/600-1850-2B-D-NA TPD32-EV-500/520-1850-4B-D-NA EMI-FN-3359-480-2500 S7EMI5
600x370x200
55 C3 / 2° / 100 m
TPD32-EV-500/600-1000-2B-E-NA ----- EMI-480-1600 S7DGO
400x300x160
34 C3 / 2° / 100 m
TPD32-EV-500/600-1300-2B-E-NA TPD32-EV-500/520-1300-4B-E-NA EMI-480-1600 S7DGO
400x300x160
34 C3 / 2° / 100 m
TPD32-EV-500/600-1400-2B-E-NA TPD32-EV-500/520-1350-4B-E-NA EMI-FN-3359-480-2500 S7EMI5
600x370x200
55 C3 / 2° / 100 m
TPD32-EV-500/600-1500-2B-E-NA TPD32-EV-500/520-1500-4B-E-NA EMI-FN-3359-480-2500 S7EMI5
600x370x200
55 C3 / 2° / 100 m
TPD32-EV-500/600-1800-2B-E-NA TPD32-EV-500/520-1800-4B-E-NA EMI-FN-3359-480-2500 S7EMI5
600x370x200
55 C3 / 2° / 100 m
TPD32-EV-500/600-2000-2B-E-NA TPD32-EV-500/520-2000-4B-E-NA EMI-FN-3359-480-2500 S7EMI5
600x370x200
55 C3 / 2° / 100 m
TPD32-EV-500/600-2200-2B-E-NA ----- n.d.
TPD32-EV-500/600-2350-2B-E-NA TPD32-EV-500/520-2350-4B-E-NA n.d.
Mains voltage 500 V ± 10%
TPD32-EV-500/600-17-2B-A-NA TPD32-EV-500/520-17-4B-A-NA EMI-600-34 S7DFM 335x60x150 1.8 C3 / 2° / 30 m
TPD32-EV-500/600-35-2B-A-NA TPD32-EV-500/520-35-4B-A-NA EMI-600-62 S7DFO 329x80x125 3 C3 / 2° / 30 m
TPD32-EV-500/600-56-2B-A-NA TPD32-EV-500/520-56-4B-A-NA EMI-600-85 S7DFP 329x80x220 4.3 C3 / 2° / 30 m
TPD32-EV-500/600-88-2B-A-NA TPD32-EV-500/520-88-4B-A-NA EMI-600-113 S7DFQ 379x90x220 5.6 C3 / 2° / 30 m
TPD32-EV-500/600-112-2B-A-NA TPD32-EV-500/520-112-4B-A-NA EMI-600-145 S7DFR
469x110x240
7.1 C3 / 2° / 30 m
TPD32-EV-500/600-148-2B-A-NA TPD32-EV-500/520-148-4B-A-NA EMI-SCHF-600-205 S7DGD
420x210x127
6.5 C3 / 2° / 30 m
TPD32-EV-500/600-224-2B-B-NA TPD32-EV-500/520-224-4B-B-NA EMI-690-320 S7DGR
230x190x116
7.2 C3 / 2° / 100 m
TPD32-EV-500/600-280-2B-B-NA TPD32-EV-500/520-280-4B-B-NA EMI-690-400 S7EMI12
230x190x116
7.5 C3 / 2° / 100 m
TPD32-EV-500/600-336-2B-B-NA TPD32-EV-500/520-336-4B-B-NA EMI-690-400 S7EMI12
230x190x116
7.5 C3 / 2° / 100 m
TPD32-EV-500/600-400-2B-B-NA TPD32-EV-500/520-400-4B-B-NA EMI-690-600 S7DGS
230x190x116
7.8 C3 / 2° / 100 m
TPD32-EV-500/600-450-2B-B-NA TPD32-EV-500/520-450-4B-B-NA EMI-690-600 S7DGS
230x190x116
7.8 C3 / 2° / 100 m
