—————— TPD32-EV ——————
148
Parameter description No.
Value
Standard
Conguration
min max
Factory
American
Factory
Standard
Enable drive
Enabled(1)
Disabled(0)
314 0 1 Disabled Disabled Terminal12
+15...30V
0V
Start/Stop
Start(1)
Stop(0)
315 0 1 Stop(0) Stop(0) Terminal13
+15...30V
0V
Ramp ref (d) [FF]
109 -32768 +32767 - - -
Ramp ref (rpm)
110 -32768 +32767 - - *
Ramp ref (%)
111 -200.0 +200.0 - - -
Ramp output (d) [FF]
112 -32768 +32767 - - -
Ramp outp (rpm)
113 -32768 +32767 - - *
Ramp output (%)
114 -200.0 +200.0 - - -
Speed ref (d) [FF]
115 -32768 +32767 - - -
Speed ref (rpm)
118 -32768 +32767 - - *
Speed ref (%)
117 -200.0 +200.0 - - -
Actual spd (d) [FF]
119 -32768 +32767 - - -
Actual spd (rpm)
122 -8192 +8192 - - AnOutput1*
Actual spd (%)
121 -200.0 +200.0 - - -
F act spd (rpm)
924 -32768 +32767 - - *
Act spd lter [s]
923 0.001 1.000 0.100 0.100 -
Enc 1 speed (rpm)
427 -8192 +8192 - - -
Enc 2 speed (rpm)
420 -8192 +8192 - - -
Mains voltage [V]
466 0 999 - - *
Mains frequency [Hz]
588 0.0 70.0 - - -
Output power [Kw]
1052 0.01 9999.99 - - -
Output voltage [V]
233 0 999 - - *
Motor current [%]
199 -250 250 - - *
F T curr (%)
928 -500 +500 - - *
T curr lter [s]
926 0.001 0.250 0.100 0.100 -
T current ref [%]
41 -200 +200 - - *
Flux reference [%]
500 0.0 100.0 - - *
Flux current [%]
234 0.0 100.0 - - *
Flux current (A)
351 0.1 99.9 S S -
Digital I/Q
- - -
Dig input term 1
565 0 1 - - -
Dig input term 2
566 0 1 - - -
Dig input term 3
567 0 1 - - -
Dig input term 4
568 0 1 - - -
Dig input term 5
569 0 1 - - -
Dig input term 6
570 0 1 - - -
Dig input term 7
571 0 1 - - -
Dig input term 8
572 0 1 - - -
Dig input term 9
573 0 1 - - -
Dig input term 10
574 0 1 - - -
Dig input term 11
575 0 1 - - -
Dig input term 12
576 0 1 - - -
Dig input term 15
579 0 1 - - -
Dig input term 16
580 0 1 - - -
Dig output term
581 0 65535 - - -
Virtual dig inp
582 0 65535 - - -
Virtual dig out
583 0 65535 - - -
  *Thisfunctioncanbeassignedtoaprogrammableanalogoutput.
