—————— TPD32-EV ——————
220
Parameter N.
Value
Standard
conguration
min max
factory
America
factory
Standard
Inversion in 3
Enabled(1)/Disabled(0)
1269 0 1 Disabled(0) Disabled(0)
Inversion in 4
Enabled(1)/Disabled(0)
1270 0 1 Disabled(0) Disabled(0)
Digital in 5
149 0 87 OFF(0) OFF(0)
Inversion in 5
Enabled(1)/Disabled(0)
1271 0 1 Disabled(0) Disabled(0)
Digital in 6
150 0 87 OFF(0) OFF(0)
Inversion in 6
Enabled(1)/Disabled(0)
1272 0 1 Disabled(0) Disabled(0)
Digital in 7
151 0 87 OFF(0) OFF(0)
Inversion in 7
Enabled(1)/Disabled(0)
1273 0 1 Disabled(0) Disabled(0)
Digital in 8
152 0 87 OFF(0) OFF(0)
Inversion in 8
Enabled(1)/Disabled(0)
1274 0 1 Disabled(0) Disabled(0)
Digital input XX Selectionoftheparameterthatisaddressedbythedigitalinputconcerned.Thefollow-
ingassignmentsarepossible:
OFF
Motor pot reset
Motor pot up
Motor pot down
Motor pot sign +
Motor pot sign -
Jog +
Jog -
Failure reset
Torque reduct
Ramp out = 0
Ramp in = 0
Freeze ramp
Lock speed reg
Lock speed I
Auto capture
Input 1 sign +
1)
Input 1 sign -
1)
Input 2 sign +
1)
Input 2 sign -
1)
Input 3 sign +
1)
Input 3 sign -
1)
Zero torque
Speed sel 0
2)
Speed sel 1
2)
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
Speed sel 2
2)
Ramp sel 0
3)
Ramp sel 1
3)
Field loss
Enable ux reg
Enable ux weak
Pad A bit 0
Pad A bit 1
Pad A bit 2
Pad A bit 3
Pad A bit 4
Pad A bit 5
Pad A bit 6
Pad A bit 7
Forward sign
Reverse sign
An in 1 target
An in 2 target
An in 3 target
Enable droop
Enable PI PID
4)
Enable PD PID
4)
PI integral freeze
4)
PID offs. Sel
4)
PI central vs0
4)
25
26
27
29
30
31
32
33
34
35
36
37
38
39
44
45
46
47
48
49
52
53
54
55
56
PI central vs1
4)
Diameter calc
4)
Diam reset
Diam calc Dis
Torque winder EN
Line acc status
Line dec status
Line fstp status
Speed match
Diam inc/dec En
Wind/unwind
Diam preset SEL0
Diam preset SEL1
Taper enable
Speed demand En
Winder side
Enable PI-PD PID
Jog TW enable
Brake fbk
5)
Adapt Sel 1
6)
Adapt Sel 2
7)
Wired FC EN
(8)
Wired FC Inv Seq
(9)
Wired FC Act Brg
(10)
57
58
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
86
87
88
89
90
 1)
 TheInput xx sign +andInput XX sign -parameterscanonlybeusedinconjunction
withtheotherparameter.
 2)
TheSpeed sel 0,Speed sel 1andSpeed sel 2parameterscanonlybeusedtogether.
 3)
 TheRamp sel 0andRamp sel 1parameterscanonlybeusedtogether.
 4)
 Refertoparagraph6.16.3PID function
 5)
Externalmechanicalbrakerelayfeedback;ifsettodigitalinput(selection:Brake
fbk),thiscommandisnecessaryinorderforthebraketobereleasedorclosed
withouttriggeringthealarm.Ifnotsettodigitalinput,itisnotconsideredinthe
brakecontrolsequence.
6)
 Gainsvalueselectionwiththesignicance2
1
7)
 Gainsvalueselectionwiththesignicance2
2
8)
 EnableseldcontrolbyTPD32-EV-FCviastandardI/O.
 9)
 Indicationifeldcontrolisduringinversionsequence
 10)
 Indicationoftheactualactivebridge(positiveornegative)oftheFCunit
