—————— TPD32-EV ——————
232
otor pot sign - Selectionofthe“Counterclockwise”rotationdirectionwhentheselectioniscarried
outvia theterminalstrip.TheMotor pot sign -parameterislinkedwiththeMotor
pot sign +parameterviaanXORfunction.Thismeansthatthecommand(+24V)must
begivenonlytooneofthetwoterminals.
 High “Counter-clockwise”rotationdirectionselected.
 Low “Counter-clockwise”rotationdirectionnotselected.
Motor pot reset. InCong1,whentheResetcommandisactivatedandthedriveisswitchedoff,the
restartbeginsat“Zero”speed.Inthiscasethecommandisonlypossiblewiththedrive
switchedoff!InCong2,thecommadispossiblealsowhenthedriveisswitchedon
andthebehaviourfollowsthecongurationofparameter Reset Cfg.
Motor pot up Thedriveisacceleratedwiththepreselectedramp.Thesettingcanbecarriedoutvia
keypadbutton,viatheterminalorBus.
Motor pot down Thedriveisdeceleratedwiththepreselectedramp.Thesettingcanbecarriedoutvia
keypadbutton,viatheterminalorBus
MPot Lower Limit Settingofthelowerlimit(RPM)ofthemotorpotvaluewhenCong2isselected..
MPot Upper Limit SettingoftheUpperlimit(RPM)ofthemotorpotvaluewhenCong2isselected..
Mpot top lim
Mpot bottom lim
Up
Down
Mpot output mon
MPot Acc Time Settingofaccelerationtime(s)betweenlowerandupperlimitssetwhenCong2is
selected.
MPot Dec Time Settingofdecelerationtime(s)betweenupperandlowerlimitssetwhenCong2is
selected.
MPot Mode FunctioningmodewhenCong2isselected.
SettingofthecongurationoftwopossibleoptionsoftheMotorpotentiometerfunction.
Therearetwooperatingmodesforeachofthetwooptions.
 Ramp&Lastval
 Ramp&Follow
 Fine&Lastval
 Fine&Follow
Option 1:
BehaviouroftheMotorpotentiometerfunctionwiththeStop or FastStop commandpresent.
Thetwooperatingmodesare:Last val or Follow.
InLast valmodewiththeStop or FastStop commandpresent,theoutputoftheMotorpotentiometerfunction
isnotmodied.
Themotorspeedmovesto0.WhentheRuncommandissent,themotorspeedmovestothespeedreferenceset
byRamp ref 1+Ramp ref 2 +themotorpotentiometeroutput
