gefran TPD32-EV-...-4B - Page 431

—————— Instruction manual ——————
431
Parameter No. Format
Value Access via
min max
Factory
American
Factory
European
Keyp.
RS485/
BUS/
Opt2-M
Term.
Opt2-A/
PDC
Overloadmode
Currlimited
Currnotlimited
I2tMotor
I2tDrive
I2tMotor&Drv
318 U16 0 4 I2tMotor Curr
limited
ü
R/W
0
1
2
3
4
- -
Overloadcurrent[%]
312 U16 P313 200 150 100
ü
R/W - -
Basecurrent[%]
313 U16 0 P312
<100
100 80
ü
R/W - -
Overloadtime[s]
310 U16 0 65535 60 30
ü
R/W - -
Ventil.Type
SERVO
AUTO
914 U16 0 1 Servo Servo
0
1
ü
R/Z - -
Deratingfactor[%]
915 U16 0 100 50 50
ü
R/Z - -
Motorovrldpreal.
1289 U16 0 1 - -
ü
R - -
MotorI2taccum
655 Float 0,00 100,00 - -
ü
R - -
Driveovrldpreal.
1438 U16 0 1 - -
ü
R - -
DriveI2taccum
1439 FLOAT 0,00 100,00 - -
ü
R - -
Pausetime[s]
311 U16 0 65535 540 300
ü
R/W - -
Overldavailable
Overloadnotpossible
Overloadpossible
406 U16 0 1 - - - R
0
1
QD
L
H
R
0
1
Overloadstate
Currentlimitvalue
Current>limitvalue
407 U16 0 1 - - - R
0
1
QD
L
H
R
0
1
START UP \ Analog inputs \ Analog input 1
Selectinput1
70 U16 0 32 Rampref Rampref
ü
R/Z - -
1(4) 1(4)
OFF 0
Jogreference 1
Speedref1 2
Speedref2 3
Rampref1 4
Rampref2 5
Tcurrentref1 6
Tcurrentref2 7
Adapreference 8
Tcurrentlimit 9
Tcurrentlim+ 10
Tcurrentlim- 11
Pad0 12
Pad1 13
Pad2 14
Pad3 15
Loadcomp 19
PIDoffset0 21
PIcentralv3 22
PIDfeed-back 23
Fluxcurrentmax 25
Outvltlevel 26
Speedratio 28
Tensionred 29
Tensionref 30
Preset3 31
BrakeRef 32
Scaleinput1
72 Float -10000 10.000 1.000 1.000
ü
R/W - -
Autotuneinp1
Autotune
259 U16
ü
C/W
1
- -
Offsetinput1
74 I16 -32768 +32767 0 0
ü
R/W - -
START UP \ Analog inputs \ Analog input 2
Selectinput2
(SelectlikeInput1)
75 U16 0 32 OFF(0) OFF(0)
ü
R/Z - -
Scaleinput2
77 Float -10.000 10.000 1.000 1.000
ü
R/W - -
