This equipment has been tested and found to comply with the respective limits in each table below, pursuant
to Part 15 of the Federal Communications Commission (FCC) Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in its intended use
environment.
Wireless Characteristics and Compliance:
This instrument complies with the requirements of FCC Part 15 Subpart B, Innovation, Science and Economic
Development Canada (ISED) ICES‑003, and EN 61326‑1:2013 as shown below:
FCC ID: 2AQV3‑GEM100
IC Certicate: 24216‑GEM100
Product Name: GEM Hemochron 100
Model(s): GEM100
Equipment Type: Wireless Handheld Hemochron
Classication: Portable Transmitter Handheld Only
TX Frequency Range: 2412–2462 MHz; 5180–5320 MHz; 5500–5700 MHz; 5745–5825 MHz
Frequency Tolerance: ±2.5 ppm
Maximum RF Output: 2450 MHz (b) – 15.50 dB, 2450 MHz (g) – 19.00 dB, 2450 MHz (n) – 21.50 dB,
5250 MHz (a) – 16.00 dB, 5250 MHz (n) – 16.00 dB, 5600 MHz (a) – 17.50 dB,
5600 MHz (n) – 17.50 dB, 5800 MHz (a) – 17.00 dB, 5800 MHz (n) – 17.00 dB Conducted
Signal Modulation: DSSS, OFDM
Antenna Type: Internal; PIFA Antenna
FCC Rule Parts: Part 2, 15C, 15E
KDB Test Methodology: KDB 447498 D01 v06, KDB 248227 v02r02, KDB 616217 D04 v01r02
Industry Canada: RSS-102 Issue 5, Safety Code 6
Maximum SAR Value: 1.02 W/kg Reported 10 Gram Average
Maximum Simultaneous
SAR:
1.45 W/kg Reported 10 Gram Average
Separation Distance: 0 mm
List of Wireless Technologies Utilized:
Band Technology
3GPP
Nominal
Power dBm
Setpoint
Nominal
Power dBm
Tolerance
dBm
Lower
Tolerance
dBm
Upper
Tolerance
dBm
WLAN – 2.4 GHz 802.11b N/A 13.5 ±2 11.5 15.5
WLAN – 2.4 GHz 802.11g N/A 17.0 ±2 15.0 19.0
WLAN – 2.4 GHz 802.11n N/A 19.5 ±2 17.5 21.5
WLAN – 5 GHz Band I, IIA 802.11a (36–56) N/A 13.0 ±2 11.0 15.0
WLAN – 5 GHz Band IIA 802.11a (60–64) N/A 14.0 ±2 12.0 16.0
WLAN – 5 GHz Band I, IIA 802.11n (36–56) N/A 13.0 ±2 11.0 15.0
WLAN – 5 GHz Band IIA 802.11n (60–64) N/A 14.0 ±2 12.0 16.0
WLAN – 5 GHz Band IIC 802.11a N/A 15.5 ±2 13.5 17.5
WLAN – 5 GHz Band IIC 802.11n N/A 15.5 ±2 13.5 17.5
WLAN – 5 GHz Band III 802.11a N/A 15.0 ±2 13.0 17.0
WLAN – 5 GHz Band III 802.11n N/A 15.0 ±2 13.0 17.0
Wireless Quality of Service (QoS):
This instrument uses wireless technology for the transmission of data to external devices. No reliance on
wireless communication is necessary for specimen analysis and/or calculation of analytical test results.
Inadequate QoS will result in a communications error agged to the Operator through the instrument user
interface. For an indicator of the network quality, see “Connectivity Icons” (page 10) .
