Δ 8.4.2.1.3 Congure Instruments (Instrument Settings)
1 Click the Instrument Settings button.
The Instrument Settings dialog box ( Figure 89 ) is displayed.
2 At the top of the dialog box, select the appropriate tab (General, LQC Settings, EQC Settings,
Barcode Settings, or Version Info).
3 Select the settings:
● General – See Figure 89 and Table 14 (page 83) .
● LQC Settings – See Figure 90 and Table 15 (page 85) .
● EQC Settings – See Figure 91 and Table 16 (page 87) .
● Barcode Settings – See Figure 92 and Table 17 (page 90) .
● Version Info – See Figure 94 and Table 18 (page 92) .
NOTE: If the value of a Yes/No drop-down list is
blank (if it is not Yes or No), the existing setting on
the instrument will remain the same when the data is
sent to the instrument.
Example: The value of this
Yes/No drop-down list is blank.
4 Click OK to save the changes and return to the Home screen.
General Settings Dialog Box:
Figure 89 : CCM – General Settings Dialog Box
Table 14: CCM – Instrument Settings > General
Setting Description
General Parameters
Allow Patient and LQC
Database Erase
Choose whether to allow Supervisors to erase (delete) test results (patient and
LQC tests) from the database using the instrument menus:
• Yes – Allow the database to be erased.
• No – Do not allow the database to be erased.
LQC Hide Choose whether to display Pass or Fail instead of numeric test results after an
LQC test:
• Yes – Displays a Pass or Fail test result.
• No – Displays a numeric test result.
Show Detailed Test
Information
Choose whether to allow Operators to see the number of patient tests allowed
after the LQC Interval expires:
• Yes – Operators can see the number of patient tests allowed.
• No – Operators cannot see the number of patient tests allowed. The number is
not shown.
OID/PID Automatic
Logout Hours
(HHH:MM 0:00–720:00)
The number of hours (0:00–720:00) before Operators are automatically logged
out.
