Maintenance
Malfunctions and troubleshooting
8
1009.25B0
IFU 1009.25 EN 01
83 / 92
8.2.3 Stationary charging station
No. Appearance / Inspection Activity / Rectification / Measure
1 Stationary charging station is con-
nected to the power, and the green
LED (voltage supply) is not lit.
Connection line to the stationary charging station is
defective.
1. Have the connection line or power supply unit
checked by authorised service technicians.
Stationary charging station is defective.
1. Have the stationary charging station checked by
authorised service technicians.
2 The control device is inserted into
the charging cradle and the green
LED (battery charge level / voltage
supply) does not flash.
The control device is not properly inserted in the
charging cradle.
1. Insert the control device properly into the cradle.
The control device is defective.
1. Have the control device checked by authorised
service technicians.
Stationary charging station is defective.
1. Have the stationary charging station checked by
authorised service technicians.
3 The orange LED (error indicator) is
lit.
Internal defect.
1. Have the stationary charging station checked by
authorised service technicians.
4 The orange LED (error indicator)
flashes quickly.
Metallic foreign object in the charging cradle pre-
vents the control unit from charging.
1. Remove metal foreign bodies from the charger.
5 Orange LED (error display) flashes
slowly.
Error in the supply voltage of the stationary char-
ging station.
1. Have the product checked by an authorised ser-
vice technician.
Tab.14: Faults and troubleshooting
