Getinge 1009.25B0 - Technical Specifications; Ambient Conditions; Electrical Specifications; Dimensions

Technical specifications
Ambient conditions
9
1009.25B0
IFU 1009.25 EN 01
85 / 92
9 Technical specifications
NOTE
For dimensions, adjustment ranges and weight specifications, there is a tolerance
of ±5 %, if no other tolerance is specified.
9.1 Ambient conditions
Temperature: Shipping / storage -20°C to +50°C
Temperature: Operation +10°C to +40 °C
Relative humidity: Shipping / storage 10% to 95%
Relative humidity: Operation 30% to 75%
(non-condensing)
Atmospheric pressure: Shipping / storage 500hPa to 1060hPa
Atmospheric pressure: Operation 700hPa to 1060hPa
9.2 Electrical specifications
Internal operating voltage IPS SELVDC3.6V
Rechargeable battery Li-ion 7.92Wh/2.2Ah
Protection against ingress of liquids IPX4 (spray water protection)
9.3 Dimensions
Length 254 mm
Width 65–75mm
Height 26-37mm
9.4 Weight
Net weight 0.4kg
