Getinge 1009.25B0 - Selecting and Approaching a User-Defined Sequence; Editing a User-Defined Sequence; Activate Control Device from Stand-By Mode; Set to Stand-By Mode

5
Operating menu
Activate control device from stand-by mode / set to stand-by mode
60 / 92
1009.25B0
IFU 1009.25 EN 01
4. Touch the SAVE WAYPOINT button.
Ø The intermediate step has been saved.
Ø The next intermediate position can be
approached.
5. Adjust the operating table further and save
corresponding intermediate positions.
Once the desired end position has been
reached:
6. Touch the SAVE SEQUENCE button.
Ø The window for naming the new se-
quence is opened.
7. Enter the name of the new sequence.
8. Touch the OK button.
Ø The new sequence is saved in the se-
lected folder.
5.5.3.3 Selecting and approaching a user-defined sequence
NOTIC E
The operating table must be aligned horizontally to carry out a user-defined adjust-
ment sequence [8Page63].
User-defined adjustment sequences are selected and carried out in the same manner as de-
scribed in the section Selecting and approaching a user-defined OR table position [8Page54]..
5.5.3.4 Editing a user-defined sequence
User-defined sequences are edited in the same manner as described in the section Editing a
user-defined OR table position [8Page55].
5.6 Activate control device from stand-by mode / set to stand-by
mode
NOTE
The control device can be activated with any button. To avoid unintentional adjust-
ment of the OR table, always use the [Stand-by] button.
NOTE
The control device will automatically switch to stand-by mode after several seconds
with no input.
NOTE
If the control device is in stand-by mode, the [Stand-by] button flashes as soon as
movement is detected.
