8
Maintenance
Malfunctions and troubleshooting
82 / 92
1009.25B0
IFU 1009.25 EN 01
8.2.2 Mobile charging station
No. Appearance / Inspection Activity / Rectification / Measure
1 Mobile charging station is connected
to the power supply, and the green
LED (voltage supply) is not lit.
Connecting cable between power supply unit and
mobile charging station is defective.
1. Have the connecting cable checked by author-
ised service technicians.
Mobile charging station is defective.
1. Have the mobile charging station checked by an
authorised service technician.
2 The control device is placed into the
charging cradle and the green LED
(status display mains connection
status indicator) does not light up.
Mobile charging station is not connected to the
mains.
1. Connect the mobile charging station to the
mains.
Connecting cable from the AC adapter to the char-
ging station is defective.
1. Have the connecting cable checked by author-
ised service technicians.
Mobile charging station is defective.
1. Have the mobile charging station checked by an
authorised service technician.
3 Orange LED is lit and control device
is not in the charging cradle
Internal defect.
1. Have the mobile charging station checked by an
authorised service technician.
4 The orange LED (error indicator)
flashes quickly.
Metallic foreign object in the charging cradle pre-
vents the control unit from charging.
1. Remove metal foreign bodies from the charger.
5 Orange LED (error display) flashes
slowly.
Error in the supply voltage of the stationary char-
ging station.
1. Have the mobile charging station checked by an
authorised service technician.
Tab.13: Faults and troubleshooting
