1.1.3.3 Definition for 3-dimensional coordinate system
Reference X axis Y axis Z axis
Product Longitudinal direction Lateral direction Height
Patient Longitudinal Transverse Sagittal
Neutral Horizontal Horizontal Vertical
Fig.1: Definition of terms for the 3-dimensional coordinate system
1 Frontal plane (horizontal plane)
2 Sagittal plane
3 Transverse plane
1.1.3.4 Definition of inclination and tilt
Fig.2: Definition of inclination and tilt
1 Reverse Trendelenburg
2 Trendelenburg (head down)
3 Lateral tilt
4 Inclination
