100 96-8000
June 1999
OPERATION
LIST PROG Selects Program List mode and displays a list of the programs in the
control.
SELECT PROG Makes the highlighted program on the program list the current program.
The current program will have an asterisk preceding it in the program list.
SEND RS232 Transmits programs out the RS-232 serial port. If ALL is highlighted, all
the programs will be sent with one îš“%îš” at the beginning and one at the
end of the stream.
RECV RS232 Receives programs from the RS-232 serial port. Unless ALL is high-
lighted, enter a valid program name in the form Onnnnn before pressing
RECV RS232. If ALL is highlighted, do not enter a program name. The
program names will be entered automatically from the input stream data.
ERASE PROG Erases the highlighted program or the program specified in the input buffer.
NUMERIC KEYS: The numeric keys give the user the ability to enter numbers and a few special characters
into the control.
CANCEL The Cancel key is used to delete the last character entered during editing or field input.
SPACE This is a space and can be used to format comments placed into programs.
WRITE / This acts as the general purpose enter key. Any time that user needs to change any
ENTER information in the control, this key is pressed.
-, . Used to negate numbers, or provide decimal precision.
+, =, These symbols are accessed by first pressing the SHIFT key and then the key with these
#, and * symbols. They are used in macro expressions.
?, %, $, These are additional symbols, accessed by pressing the SHIFT key. They can be used
!, &, @, in program comments.
and :
