474
TECHNICAL REFERENCE
June 1999
96-8000
12.20 DISCRETE I NPUTS / OUTPUTS
The inputs/outputs that are followed by an asterisk (*) are active when equal to zero (0).
DISCRETE INPUT
# Name # Name
1OOO TC Changer In 1O16 Spindle Lock (Vector Drive: spare)
1OO1 TC Changer Out 1O17 Spindle Fault (Vector Drive: spare)
1OO2 Tool One In Pos. 1O18 Spindle Stopped* (Vector Drive: spare)
1OO3 Low TSC Pressure 1O19 Spindle At Speed* (Vector Drive: spare)
1OO4 Tool In Position 1O20 Low Trans Oil Prs
1OO5 Spindle High Gear 1O21 Spare 1
1OO6 Spindle Low Gear 1O22 Spare 2
1OO7 Emergency Stop 1O23 Spare 3
1OO8 Door Switch 1O24 Tool Unclmp Rmt*
1O09 M Code Finish* 1O25 Low Phasing 115V
1O10 Over Voltage 1O26 Spare 3A
1O11 Low Air Pressure 1O27 Spare 3B
1O12 Low Lube Press. 1O28 Ground Fault
1O13 Regen Over Heat 1O29 G31 Block Skip
1O14 Draw Bar Open 1O30 Spigot Position
1O15 Draw Bar Closed 1O31 Conveyr Overcrnt
The inputs are numbered the same as the connections on the inputs printed circuit board.
DISCRETE OUTPUTS
# Name # Name
1100 Powered Servos 1116 Move Spigot CW
1101 Spindle Forward (Vector Drive: spare) 1117 Move Spigot CCW
1102 Spindle Reverse (Vector Drive: spare) 1118 Pal Ready Light
1103 Reset Spind. Drv (Vector Drive: spare) 1119 TSC Purge
1104 Brake 4th Axis 1120 Unclamp Pre-Chrg
1105 Coolant Pump On 1121 HTC Shuttle Out (Air Drive Shuttle: Move shuttle in)
1106 Auto Power Off 1122 Brake 5TH Axis
1107 Spind. Motor Fan 1123 CE Door Lock
1108 Move T.C. In 1124 M21
1109 Move T.C. Out 1125 M22
1110 Rotate T.C. CW 1126 M23 (Air Drive Shuttle: Move Shuttle Out)
1111 Rotate T.C. CCW 1127 TSC Coolant
1112 Spindle Hi Gear 1128 Green Beacon On
1113 Spindle Low Gear 1129 Red Beacon On
1114 Unclamp Tool 1130 Enable Conveyor
1115 Lock Spindle (Vector Drive: spare) 1131 Reverse Conveyor
Note: If the machine is equipped with an APC the following inputs and outputs will
change:
