Haas VF Series Operator's Manual

96-8000
M CODES
211
June 1999
6. M CODES (MISCELLANEOUS FUNCTIONS)
M CODE S UMMARY
Only one M code may be programmed per block of a program. All M codes are effective or cause an action to
occur at the end of the block. However, when Parameter 278 bit "CNCR SPINDLE" is set to 1, an M03 (spindle
start) will occur at the beginning of a block.
M00 Stop Program
M01 Optional Program Stop
M02 Program End
M03 Spindle Forward
M04 Spindle Reverse
M05 Spindle Stop
M06 Tool Change
M08 Coolant On
M09 Coolant Off
M10 Engage 4th Axis Brake
M11 Release 4th Axis Brake
M12 Engage 5th Axis Brake
M13 Release 5th Axis Brake
M16 Tool Change (same as M06)
M19 Orient Spindle
M21-M24 Optional Pulsed User M Function with Fin
M30 Prog End and Rewind
M31 Chip Conveyor Forward
M32 Chip Conveyor Reverse
M33 Chip Conveyor Stop
M34 Increment Coolant Spigot Position
M35 Decrement Coolant Spigot Position
M36 Pallet Rotate
M39 Rotate Tool Turret
M41 Low Gear Override
M42 High Gear Override
M51-M54 Set Optional User M
M61-M64 Clear Optional User M
M75 Set Measure point
M76 Disable Displays
M77 Enable Displays
M78 Alarm if skip signal found
M79 Alarm if skip signal not found
M82 Tool Unclamp
M86 Tool Clamp
M88 Through the Spindle Coolant ON
M89 Through the Spindle Coolant OFF
M95 Sleep Mode
M96 Jump if no Input
M97 Local Sub-Program Call
M98 Sub Program Call
M99 Sub Program Return Or Loop

Haas VF Series Specifications

General

Machine Type	Vertical Machining Center
Control	Haas CNC Control
Z-Axis Travel	20-30 inches (varies by model)
Y-Axis Travel	16 - 30 inches (varies by model)
Spindle Motor	20-30 hp (depending on model)
Tool Capacity	20-40 tools (varies by model)
