Haas VF Series - MACHINE FOOTPRINT: VF-11

33
INSTALLATION
June 1999
96-8000
MACHINE F OOTPRINT: VF-11
37.35
(64.9 cm)
159.60
(405.4 cm)
98.60
(250.0 cm)
257.00
(652.8 cm)
52.00 MIN.
(132.0 cm)
DOOR
SWING
60.00 MIN.
(152.4 cm)
40.20
(102.0 cm)
72.80
(185.0 cm)
COO
LANT TANK
BASE
CASTING
FRONT
5.04
(12.8 cm)
