96-8000 407
OPTIONS
June 1999
TSC M CODES
The following M codes apply only to the Through The Spindle Coolant system:
M88 Thru Spindle Clnt ON
M88 performs the following operations:
- Stop the spindle
- Turn on the TSC pump
- Wait for coolant pressure
- Restart spindle
M89 Thru Spindle Clnt OFF
M89 performs the following operations:
- Stop the spindle
- Turn off the TSC pump
- Turn on purge
- Wait for [Parameter 237] for coolant to purge
- Turn off purge
The following pre-existing M codes perform a slightly different function when Through the Spindle Coolant is
turned ON:
M00 Stop Prog
M01 Optional Stop
When TSC is ON, M00 and M01 will shut it OFF, as in M89.
M06 Tool Change
When TSC is ON, M06 causes the following operations to be performed:
- Orient the spindle and move Z-axis to tool change position
- Turn OFF the TSC pump
- Turn on purge
- Wait for [Parameter 237] for coolant to purge
- Turn off purge
- Perform tool change
TSC then remains OFF until M88 is used.
M24 Option User M
When TSC is enabled, this M code is disabled.
M30 Prog End Rew
When TSC is ON, M30 will shut it OFF as in M89, then perform an M30 operation.
