Haas VF Series Operator's Manual

96-8000 403
OPTIONS
June 1999
SPIGOT P ARAMETERS
The parameters that control the spigot are below. Refer to the "Parameters" section for a complete description
of their usage.
SPIGOT POSITIONS Parameter 206
SPIGOT TIMEOUT (MS) Parameter 207
SPIGOT M CODES
M34 Increment Coolant Spigot Position
M34 increments the current spigot position one place. Incrementing the spigot position causes the spigot to
advance away from the spigot home position. The home position is designated as zero. If the current spigot
position is 5 and M34 is executed, then the current spigot position will advance to position 6. The Spigot home
position for a horizontal mill places the spigot at the most positive Z axis location that the spigot can attain.
Incrementing the spigot then lowers the coolant stream direction.
M35 Decrement Coolant Spigot Position
M35 Decrements the current spigot position one place. Decrementing the spigot position causes the spigot to
move toward the spigot home position. The home position is designated as zero. If the current spigot position
is 5 and M35 is executed, then the current spigot position will move to 4. The Spigot home position for a
horizontal mill places the spigot at the most positive Z axis location that the spigot can attain. Decrementing
the spigot will raise the coolant stream direction.

Haas VF Series Specifications

General

Machine Type	Vertical Machining Center
Control	Haas CNC Control
Z-Axis Travel	20-30 inches (varies by model)
Y-Axis Travel	16 - 30 inches (varies by model)
Spindle Motor	20-30 hp (depending on model)
Tool Capacity	20-40 tools (varies by model)
