Haas VF Series Operator's Manual

96-8000
FUNCTIONS
151
June 1999
WARMUP C OMPENSATION
When the machine is powered on, if setting 109, and at least one of Settings 110, 111 or 112 are set to a
nonzero value, the following warning will be displayed:
CAUTION! Warm-up Compensation is specified!
Do you wish to activate
Warm-up Compensation (Y/N)?
If the operator responds 'Y', the control immediately applies the total compensation, (setting 110,111 and/ or
112), and the compensation begins to decrease as the time elapses. For instance after 50% of the time in
Setting 109 has elapsed, the compensation distance for the X-axis, in Setting 110, will be 50%.
As with other settings, the Warm-up Compensation Settings can be changed at any time. Updating the Warm-
up Compensation Time may activate compensation, but changes to the X, Y or Z distance settings will not
activate compensation. To "restart" the time period, it is necessary to power the machine off and on and
answer "yes", to the compensation query at start-up.
WARNING!
Changing settings 110, 111 or 112 while compensation is in progress
can cause a sudden movement of up to 0.0044 inches.
The amount of remaining warmup time is displayed on the bottom right hand corner of the Diagnostics Inputs 2
screen using the standard hh:mm:ss format. The initial amount of warmup time to be used, starting when
power is applied, is specified in Setting 109 WARMUP TIME IN MIN.

Haas VF Series Specifications

General

Machine Type	Vertical Machining Center
Control	Haas CNC Control
Z-Axis Travel	20-30 inches (varies by model)
Y-Axis Travel	16 - 30 inches (varies by model)
Spindle Motor	20-30 hp (depending on model)
Tool Capacity	20-40 tools (varies by model)
