Haas VF Series Operator's Manual

TECHNICAL REFERENCE
459
June 1999
96-8000
MOTOR C ONTROLLER (MOCON) - BRUSHLESS
The brushless machining centers are equipped with a microprocessor based brushless motor controller board
(MOCON) that replaces the motor interface in the brush type controls. It runs in parallel with the main proces-
sor, receiving servo commands and closing the servo loop around the servo motors.
In addition to controlling the servos and detecting servo faults, the motor controller board, (MOCON), is also in
charge of processing discrete inputs, driving the I/O board relays, commanding the spindle and processing the
jog handle input. Another significant feature is that it controls 6 axes, so there is no need for an additional
board for a 5 axis machine.
P1 Data Buss
P2 X amplifier control and fault sensing (610)
P3 Y amplifier control and fault sensing (620)
P4 Z amplifier control and fault sensing (630)
P5 A amplifier control and fault sensing (640)
P32B amplifier control and fault sensing (640B)
P33C amplifier control and fault sensing (640C)
P6 X encoder input (660)
P7 Y encoder input (670)
P8 Z encoder input (680)
P9 A encoder input (690)
P30B encoder input (690B)
P31C encoder input (690C)
P18Jog encoder input (750)
P20Spindle encoder input (1000)
P10Inputs from I/O board (550)
P11I/O relays K1-8 (510)
P12I/O relays K9-16 (520)
P13I/O relays K17-24 (530)
P14I/O relays K25-32 (540)
P15Low Voltage Power (860)
P16Spindle command output (720)
P19Address bus
P24Axis home switches (990)
