Haas VF Series Operator's Manual

9
INSTALLATION
June 1999
96-8000
WARNING!
WHEN THE MACHINE IS OPERATING AND THE PRESSURE GAUGE (ON THE
MACHINE REGULATOR) DROPS BY MORE THAN 10 PSI DURING TOOL
CHANGES, INSUFFICIENT AIR IS BEING SUPPLIED TO THE MACHINE.
INSTALLATION T OOLS R EQUIRED
Precision bubble level (0.0005 inch per 10") Test indicator (0.0005)
1 1/8" hex wrench or ratchet 3/4" wrench
1 1/2" wrench Claw hammer
Forklift with the following specifications:
E/O-FV TXE/EO-FV 1-FV 2-FV 3-FV 4-FV 04/5-FV
*thgieWenihcaM000,7009,7001,7000,8005,21000,31005,41
htgneLkroF'8'8'8'8'8'8'8
05/5-FV6-FV7-FV8-FV9-FV01-FV11-FV
*thgieWenihcaM006,41001,2000,32000,42000,52000,82004,92
htgneLkroF'8'8'8'8'8'8'8
* The forklift must be capable of lifting at least this weight.
MATERIALS R EQUIRED
Wire and air hose or piping as specified in the Service Requirements section
A small amount of grease
Way lube for the lubricator (Vactra #2)

Haas VF Series Specifications

General

Machine Type	Vertical Machining Center
Control	Haas CNC Control
Z-Axis Travel	20-30 inches (varies by model)
Y-Axis Travel	16 - 30 inches (varies by model)
Spindle Motor	20-30 hp (depending on model)
Tool Capacity	20-40 tools (varies by model)
