OPTIONS
June 1999
PARAMETERS
Parameter 278 bit 26 S MNT BIT 1
Bits 26,27, and 28 work together to enable the Vertical mill side- mount tool changers. See below.
Parameter 278 bit 27 S MNT BIT 2
Bits 26,27, and 28 work together to enable the Vertical mill side- mount tool changers. See below.
Parameter 278 bit 28 S MNT BIT 3
Bits 26,27, and 28 work together to enable the Vertical mill side- mount tool changers.
The following table shows the bit combinations that must be used:
Bit 28 27 26 Decimal value Type
0000 No side-mount tool changer installed
0011 Serpentine 1
0102 Serpentine 2
0113 Serpentine 3
1004 Disk 1
1015 Disk 2
1106 Disk 3
1117 Disk 4
Parameter 60 TURRET START DELAY
On mills with a serpentine type 1 tool changer, this parameter is used to specify the time (in
milliseconds) allowed to move the carousel to the high cam position. If the carousel does not move
to its commanded position within the time allowed by this parameter, alarm 625 INVALID TC START
CONDITION is generated.
On mills with the Disk type 1 tool changer, this parameter is used to specify the time (in milliseconds)
allowed for the carousel to move off the TC mark. If the carousel has not moved within the time allowed
by this parameter, alarm 625 INVALID TC START CONDITION is generated.
Parameter 61 TURRET STOP DELAY
On mills with a serpentine type 1 tool changer, this parameter is used to specify the time (in
milliseconds) allowed to move the carousel from the start of the high cam position until the shot pin
falls into place at the low cam position. If the carousel does not move to its commanded position within
the time allowed by this parameter, alarm 625 INVALID TC START CONDITION is generated.
On mills with the Disk type 1 tool changer, this parameter is used to specify the time (in milliseconds)
allowed for the carousel to move to the TC mark. If the carousel has not moved within the time allowed
by this parameter, alarm 625 INVALID TC START CONDITION is generated.
Parameter 62 SHUTTLE START DELAY
On mills with a serpentine type 1 or Disk type 1 tool changer , this parameter is used to specify
the time (in milliseconds) needed to allow the tool pocket to settle (stop bouncing) after being lowered
in preparation for a tool change.

Haas VF Series Specifications

General

Machine Type	Vertical Machining Center
Control	Haas CNC Control
Z-Axis Travel	20-30 inches (varies by model)
Y-Axis Travel	16 - 30 inches (varies by model)
Spindle Motor	20-30 hp (depending on model)
Tool Capacity	20-40 tools (varies by model)
