Haas VF Series Operator's Manual

464
TECHNICAL REFERENCE
June 1999
96-8000
VOLTAGE S ELECTION T APS
There are four labeled plastic terminal blocks. Each block has three connections for wires labeled 74, 75, and
76. Follow the instructions printed on the transformer.
SECONDARY C ONNECTION T O T1
The secondary output from T1 is 115V AC three-phase CB2 protects the secondary of transformer T1 and is
rated at 25 amps.
OPTIONAL 480 TRANSFORMER
Voltage Selection Taps for the 480 Transformer:
Right to left:
354 to 376
377 to 402
403 to 428
429 to 457
458 to 488*
* 480 V transformer has additional terminal block

Haas VF Series Specifications

General

Machine Type	Vertical Machining Center
Control	Haas CNC Control
Z-Axis Travel	20-30 inches (varies by model)
Y-Axis Travel	16 - 30 inches (varies by model)
Spindle Motor	20-30 hp (depending on model)
Tool Capacity	20-40 tools (varies by model)
