Haas VF Series Operator's Manual

96-8000
FUNCTIONS
147
June 1999
X0. Y0. ;
X1. Y0. ;
X2. Y0. ;
X0. Y1. ;
X1. Y1. ;
X2. Y1. ;
X0. Y2. ;
X1. Y2. ;
X2. Y2. ;
M99 (END OF SUBROUTINE) ;
O0300 (EXAMPLE USING A LOCAL SUBROUTINE)
G54 G00 G90 X0. Y0.;
G81 R0.2 Z-0.1 F20 L0 (NO OPERATION HERE, JUST DEFINE CANNED CYCLE);
S2000 M03;
M97 P0500 (CENTER DRILL EACH HOLE);
T02 M06 (PECK DRILL);
G83 R0.2 Z-1. F10. L0 (NO OPERATION HERE, JUST DEFINE CANNED CYCLE);
S1000 M03;
M97 P0500 (PECK DRILL EACH HOLE);
G28 M30 (END OF MAIN PROGRAM);
N0500 (LOCAL SUBROUTINE EXAMPLE LISTING ALL HOLE POSITIONS);
X0. Y0,;
X1. Y0.;
X2. Y0.
X0. Y1.
X1. Y1.
X2. Y1.
X0. Y2.
X1. Y2.
X2. Y2.
M99 (END OF SUBROUTINE);
