Haas VF Series Operator's Manual

160
G CODES
96-8000
June 1999
G72 00 Bolt Holes Along an Angle (Yasnac) 181
G73 09 High Speed Peck Drill Canned Cycle 184
G74 09 Reverse Tap Canned Cycle 186
G76 09 Fine Boring Canned Cycle 187
G77 09 Back Bore Canned Cycle 188
G80 09* Canned Cycle Cancel 189
G81 09 Drill Canned Cycle 189
G82 09 Spot Drill Canned Cycle 190
G83 09 Normal Peck Drill Canned Cycle 191
G84 09 Tapping Canned Cycle 193
G85 09 Boring Canned Cycle 194
G86 09 Bore/Stop Canned Cycle 195
G87 09 Bore/Stop/Manual Retract Canned Cycle 196
G88 09 Bore/Dwell/Manual Retract Canned Cycle 197
G89 09 Bore/ Dwell Canned Cycle 198
G90 03* Absolute 198
G91 03 Incremental 199
G92 00 Set Work Coordinates - FANUC or HAAS 199
G92 00 Set Work Coordinates - YASNAC 199
G93 05 Inverse Time Feed Mode 199
G94 05 Feed Per Minute Mode 200
G98 10* Initial Point Return 200
G99 10 R Plane Return 200
G100 00 Cancel Mirror Image 200
G101 00 Enable Mirror Image 200
G102 00 Programmable Output To RS-232 201
G103 00 Limit Block Buffering 202
G107 00 Cylindrical Mapping 202
G110 12 Select Work Coordinate System 7 206
G111 12 Select Work Coordinate System 8 206
G112 12 Select Work Coordinate System 9 206
G113 12 Select Work Coordinate System 10 206
G114 12 Select Work Coordinate System 11 206
G115 12 Select Work Coordinate System 12 206
G116 12 Select Work Coordinate System 13 206
G117 12 Select Work Coordinate System 14 206
G118 12 Select Work Coordinate System 15 206
G119 12 Select Work Coordinate System 16 206
G120 12 Select Work Coordinate System 17 206
G121 12 Select Work Coordinate System 18 206
G122 12 Select Work Coordinate System 19 206
G123 12 Select Work Coordinate System 20 206
G124 12 Select Work Coordinate System 21 206
G125 12 Select Work Coordinate System 22 206
G126 12 Select Work Coordinate System 23 206
G127 12 Select Work Coordinate System 24 206
G128 12 Select Work Coordinate System 25 206
G129 12 Select Work Coordinate System 26 206
G136 00 Automatic Work Offset Center Measurement 170
G141 07 3D+ Cutter Compensation 206
G143 08 5 AX Tool Length Compensation (optional) 206
G150 00 General Purpose Pocket Milling 208
G174/184 00 General-Purpose Rigid Tapping (optional) 210
G187 00 Accuracy Control for High Speed Machining 210

Haas VF Series Specifications

General

Machine Type	Vertical Machining Center
Control	Haas CNC Control
Z-Axis Travel	20-30 inches (varies by model)
Y-Axis Travel	16 - 30 inches (varies by model)
Spindle Motor	20-30 hp (depending on model)
Tool Capacity	20-40 tools (varies by model)
