36796-8000
MACROS
June 1999
#3026 Tool in spindle (read only)
#3027 Spindle RPM (read only)
#3901 M30 count 1
#3902 M30 count 2
#4001-#4020 Previous block group codes
#4101-#4126 Previous block address codes
NOTE: Mapping of 4101 to 4126 is the same as the alphabetic addressing of îš“Macro
Argumentsîš” section.
#5001-#5005 Previous block end position
#5021-#5025 Present machine coordinate position
#5041-#5045 Present work coordinate postion
#5061-#5064 Present skip signal position
#5081-#5085 Present tool offset
#5201-#5206 Common offset
#5221-#5226 G54 work offsets
#5241-#5246 G55 work offsets
#5261-#5266 G56 work offsets
#5281-#5286 G57 work offsets
#5301-#5306 G58 work offsets
#5321-#5326 G59 work offsets
#5401-#5500 Tool feed timers (seconds)
#5501-#5600 Total tool timers (seconds)
#5601-#5699 Tool life monitor limit
#5701-#5800 Tool life monitor counter
#5801-#5900 Tool load monitor maximum load sensed so far
#5901-#6000 Tool load monitor limit
#6001-#6277 Settings (read only)
#6501-#6999 Parameters (read only)
Note: The low order bits of large values will not apear in the macro variables for
settings and parameters
#7001-#7005 G110 additional work offsets
#7021-#7025 G111 additional work offsets
#7041-#7045 G112 additional work offsets
#7061-#7065 G113 additional work offsets
#7081-#7085 G114 additional work offsets
#7101-#7105 G115 additional work offsets
#7121-#7125 G116 additional work offsets
#7141-#7145 G117 additional work offsets
#7161-#7165 G118 additional work offsets
#7181-#7185 G119 additional work offsets
#7201-#7205 G120 additional work offsets
#7221-#7225 G121 additional work offsets
#7241-#7245 G122 additional work offsets
#7261-#7265 G123 additional work offsets
#7281-#7285 G124 additional work offsets
#7301-#7305 G125 additional work offsets
#7321-#7325 G126 additional work offsets
#7341-#7345 G127 additional work offsets
#7361-#7365 G128 additional work offsets
#7381-#7385 G129 additional work offsets
