476
TECHNICAL REFERENCE
June 1999
96-8000
The following Discrete Inputs / Outputs 2 are available when parameter 278 SMNT BIT 1,2 or 3 (Side Mount
Tool Changer) is set and parameter 209 MCD RLY BRN (M-Code relay board) is ON.
DISCRETE INPUTS 2
Name Name
Spare Input 4A Spare Input 8A
Spare Input 4B Serp. Shot Pin*
Spare Input 5A Motor Stop
Spare Input 5B Origin
Spare Input 6A Clamp / Unclamp
Spare Input 6B Serp. Cam Count
Spare Input 7A Spare Input 11A
Spare Input 7B Spare Input 11 B
DISCRETE OUTPUTS 2
Name Name
Spare Output 40 Spare Output 48 (SMTC: Serp. ATC Enable)
Spare Output 41 Spare Output 49 (SMTC: Serp. ATC Rev.)
Spare Output 42 Spare Output 50 (SMTC: Serp. Carsl CW)
Spare Output 43 Spare Output 51 (SMTC: Serp. Carsl CCW)
Spare Output 44 Spare Output 52 (SMTC: Serp. Carsl Ena.)
Spare Output 45 Spare Output 53
Spare Output 46 Spare Output 54
Spare Output 47 Spare Output 55
ANALOG DATA
Name Description
DC BUSS Voltage from Haas Vector Drive (if equipped)
uP TEMP Microprocessor enclosure temperature (dis
played only when Parameter 278 bit "uP ENCL
TEMP" is set to 1)
SP LOAD Spindle load in %
SP SPEED Spindle RPM CW or CCW
RUN TIME Machine total run time
TOOL CHANGES Number of tool changes
VER X.XXX Software version number
MOCON MOCON software version
YY/MM/DD Today's date
MDL HS__ Machine model
