104 Connection
HBM QuantumX
6.8.3 Receiving CAN messages
To enable CAN messages to be received, it is essential that the relevant messages can be
identified by the node. This may be done directly at the node or, in a reproducible way, by
previously generated messages in the sensor database. Individual messages can be linked
to the node by drag & drop from the sensor database.
Type *.dbc CAN databases, too, can be loaded into the sensor database. Should a CAN
database not be available, it can be generated by the user. Editors for this purpose are
provided by different companies.
Received CAN messages are instantly ”time−stamped” in the measurement mode. This
enables directly acquired measured quantities and CAN messages to be acquired and
analyzed in parallel and synchronously in the entire system.
Note
MX471 is not a classical data logger that logs the complete CAN data stream on the bit
level. The parameterized node ”listens” on the CANbus and extracts the signals from
the relevant CAN messages to transmit them as measured values.
