106 Connection
HBM QuantumX
6.9 MX1601 amplifier
Up to 16 freely configurable inputs for voltage (10 V, 100 mV) or current (20 mA) or
current−fed piezoelectric sensors (IEPE) can be connected to the MX1601 amplifier.
The transducers are connected via 8−pin plug terminal connectors (Phoenix Contact FMC
1,5/8−ST−3,5−RF (order no. 1952089)).
All measuring channels are electrically isolated von one another and from the mains. When
using the adjustable transducer excitation, electrical isolation from the supply voltage of the
amplifier is not required.
MX1601 connectable transducers
Transducer type MX1601
connectable
transducers
see page
Voltage 1 ... 16 125, 126
Current 1 ... 16 127
Current fed piezoelectric transducer
(IEPE, ICP
)
1 ... 16 122
