148 Functions and outputs
HBM QuantumX
7.2 MX460
The MX460 supports 4 special math channels for analysis of rotational parts: Rotational
vibration and angle difference.
Fig. 7.2: MX460 front view
MX460 Math channels
Keep in mind the following notes when working with these channels:
S The maximum sample rate is restricted to 4800 (2400) Hz
S The sample rate of the channel must not be higher than the sample rate of the input
channel
S Filters set for the MX460 do not apply to math channels. These channels are always
unfiltered.
However, the input signal is filtered.
