3 Software
The supplied QuantumX System CD contains a powerful software package consisting of the
QuantumX Assistant, Lab View library, programming library for .NET/COM, TEDS-Editor,
FireWire driver as well as a program for module firmware updating. catman[EASY and
DIAdem driver are software products that can be obtained as separate product packages.
3.1 QuantumX Assistant
The HBM software ”QuantumX Assistant” offers the following functions:
System..
• Create survey (modules, host PC)
Modules:
• Search and configuration (e.g. TCP/IP communication), naming
• Reset to factory settings
• Read factory calibration certificate
• Analysis (information, status, log file)
• Save configuration to operating PC
Channels/sensors:
• Configuration (name, connection type, TEDS, semi-automatic assignment)
• Measurement (alphanumeric display)
• Open the TEDS editor and read/write to TEDS
• Activate/deactivate isochronous operation via FireWire
Individual signals:
• Set sampling rate and filter (type, cut-off frequency)
Measured values (Scope):
• Start/Stop continuous graphic measurements (time frames, trigger, zoom)
• Basic signal analysis (X-Y cursor)
• Record measurements
Functions and outputs
• Generate new signals using mathematics functions (peak value, rms value, adding and
multiplying, rotation)
Sensor database
• Output signals (scaled, filteresd)
• Modify and expand existing sensor databases (e.g. own sensors, dbc data files)
